BASIC OPERATIONS ON DVD DECK
Page 34Saturday, 30 October 2004 16:18
Display During Live Memory Playback
During recording, you can watch at your will what was previously recorded or is currently being recorded. It is possible to perform freely
normal playback operations (forward/reverse high-speed search and variable-speed search) within the range of the red or blue bar on the
TV screen.
When Live Memory Playback reaches the point of 30 seconds before the current recording point by forward high-speed search or other
operations, the unit returns to normal playback.
The superimpose display appears by pressing ON SCREEN.
(墌 pg. 16)
The Live Check picture is displayed on the bottom right corner by pressing LIVE CHECK.
Recording counter display
(remaining time)
Recording mark
Recording channel
Live Memory Playback mark
Live Check picture
Disc used
Bar meter (see below)
Capacity of a disc
This unit displays the current recording/playback status by the bar meter.
(Example of bar meter display)
Recorded
Total length of the program being played
Current playback position
Not recorded
While stopped
During playback
While recording
Live Memory Playback
Live Memory Playback of
another program
Capacity of a disc
Capacity of a disc
Capacity of a disc
Current playback position
Current recording position
Current recording position
Current recording position
Remaining capacity when recording started
Recording start position
Recording start position
Current playback position
Total length of the program being played back
Blue (recorded part)
Orange (recording part)
Green (playing part)
Black (unrecorded or unplayed part)
Recording mark
Recording mode
