1-68 (No. 52152)
NTSC/PAL SIGNAL WHITE BALANCE (HIGH: D9300, LOW: D65) ADJUSTMENTS
Measuring Instruments Signal generator (10-step gray scale signal)
Color temperature meter
Card (Slot) NTSC/PAL Video Input Card (Slot 2)
Test Points
Adjustment Points W*01 (Drive (R)), W*03 (Drive (B)), W*04 (Cut Off (R)),
W*05 (Cut Off (G)), W*06 (Cut Off (B)) [Service Menu]
Notes:
• Perform the following adjustments after completing the 1080/60i White Balance (High: D9300, Low: D65) Adjustments.
• Set the COLOR TEMP./BAL. data in the Setup Menu to “00”.
• The values adjusted with WW (see the description of the Component Signal White Balance (High: D9300) adjustment)
become the reference values for the white balance (high: D9300) adjustment. When this data is changed, it is required
to re-adjust the white balance (high: D9300) data of all of the adjustment signals (Component, NTSC and PAL).
• The values adjusted with WX (see the description of the Component Signal White Balance (Low: D65) adjustment)
become the reference values for the white balance (low: D65) adjustment. When this data is changed, it is required to
re-adjust the white balance (low: D65) data of all of the adjustment signals (Component, NTSC and PAL).
<HIGH: D9300>
(1) Apply the NTSC 10-step gray scale signal to INPUT C (Terminal VIDEO1 of the NTSC/PAL Video Input Card).
(2) Set “COLOR TEMP.” of COLOR TEMP./BAL. in the Setup Menu to HIGH.
(3) Set the PHASE, CHROMA, BRIGHT and CONTRAST potentiometers on the front panel to the center click positions.
(4) Adjust WA01 and WA03 in the Service Menu using the color temperature meter so that the color temperature is set as shown
below.
(Do not touch WA02.)
Color temperature : HIGH (D9300). x = 0.283, y = 0.297 (Reference value)
(5) Ensure that the white balance tracking is correct from the gray scale steps with lower color temperatures to those with higher
color temperatures. If the white balance tracking is deviated in darker steps, adjust WA04 to WA06 to correct it.
(Do not set the values of WA04 to WA06 no more than “50”.)
<LOW: D65>
(6) Set “COLOR TEMP.” of COLOR TEMP./BAL. in the Setup Menu to LOW.
(7) Adjust WB01 and WB03 in the Service Menu using the color temperature meter so that the color temperature is set as shown
below.
(Do not touch WB02.)
Color temperature : LOW (D65). x = 0.313, y = 0.329 (Reference value)
(8) Ensure that the white balance tracking is correct from the gray scale steps with lower color temperatures to those with higher
color temperatures. If the white balance tracking is deviated in darker steps, adjust WB04 to WB06 to correct it.
(Do not set the values of WB04 to WB06 no more than “50”.)
(9) Vary the adjustment signal and adjustment data, and re-perform adjustments in steps 1 to 8 above (see Table 20).
Table 20
Adjustment Signal Function
Adjustment Data
RGB
NTSC (Common to VIDEO and Y/C)
Drive WA01 – WA03
[HIGH : D9300]
Cut off WA04 WA05 WA06
NTSC (Common to VIDEO and Y/C)
Drive WB01 – WB03
[LOW : D65]
Cut off WB04 WB05 WB06
PAL (Common to VIDEO and Y/C)
Drive WC01 – WC03
[HIGH : D9300]
Cut off WC04 WC05 WC06
PAL (Common to VIDEO and Y/C)
Drive WD01 – WD03
[LOW : D65]
Cut off WD04 WD05 WD06
To Next Page
