13
ENGLISH
7 Lock Button ( pg. 16)
8 Power/Mode Switch [OFF (CHARGE), ON,
MODE] ( pg. 16)
9 Grip Strap ( pg. 18)
: Camera Sensor ( pg. 12)
; Remote Sensor ( pg. 11)
< LED Light ( pg. 22)
= Lens Cover ( pg. 18)
> Lens
? Lens Hood ( pg. 10)
@ Shoe
A Microphone Input Connector [MIC]
B USB (Universal Serial Bus) Connector [
2
]
( pg. 46, 55, 64)
C Lens Cover Switch [
=
,
>
] ( pg. 18)
D Focus Assist Button [FOCUS ASSIST]
( pg. 25)
E LED Light Button [LIGHT] ( pg. 22)
F SD Card Slot ( pg. 19)
G Stud Hole ( pg. 18)
H Tripod Mounting Socket ( pg. 18)
I Battery Release Button [BATT.] ( pg. 16)
J Battery Pack Mount ( pg. 16)
Remote Control
Q Infrared Beam Transmitting Window
R ZOOM (T/W) Buttons
Zoom In/Out
S Up Button
Rotate Button (counterclockwise)
(
 pg. 30)
T Skip Backward Button
U Left Button
V Back Button
W PLAYLIST Button ( pg. 43)
X START/STOP Button
Y SNAPSHOT Button ( pg. 21)
Z INFO Button ( pg. 39)
a Skip Forward Button
b PLAY/PAUSE Button
c Right Button
d Next Button
e Down Button
Rotate Button (clockwise) ( pg. 30)
f INDEX Button
g DATE Button
Camera
! Index Button [INDEX] ( pg. 31)/
Remaining Space Button/Data Battery
Button [ 0 / 1 ] ( pg. 18, 23)
# Set Lever
Move to ¡ :
Reverse Skip ( pg. 29)/Up/ Backlight
Compensation Button [BACK LIGHT]
( pg. 25)
Move to ¢ :
Forward Skip ( pg. 29)/Down/ Manual
Focus Button [FOCUS] ( pg. 25)
Move to £ :
Reverse Search ( pg. 29)/Left/
Nightalive [NIGHT] ( pg. 25)
Move to ¤ :
Forward Search ( pg. 29)/Right/
Program AE [PROGRAM AE] ( pg. 24)
Press down:
Play/Pause ( pg. 29)
$ Playback/Recording Mode Switching
Button [SELECT PLAY/REC] ( pg. 20)
% Auto/Manual Mode Button [AUTO]
( pg. 24) /Information Button [INFO]
( pg. 39)
& Function Button [FUNCTION] ( pg. 26)
( LCD Monitor
) S Connector [S] ( pg. 36, 50)
* Direct Backup Button [DIRECT BACK
UP] ( pg. 56)/Event Button [EVENT]
( pg. 22)
+ Speaker
, Menu Button [MENU] ( pg. 17, 66)
- Audio/Video Connector [AV] ( pg. 36, 50)
. DC Input Connector [DC] ( pg. 16)
/ Access/Charge Lamp [ACCESS/CHARGE]
(
 pg. 16)
(Blinks when you access fi les or charge
the battery. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Video/Still Image Mode Lamp [ !, # ]
( pg. 20, 21)
0 Still Image Shooting Button [SNAPSHOT]
( pg. 21)
1 Zoom Lever [W 7 , T
,
] ( pg. 22)
Speaker Volume Control [–VOL+]
( pg. 29)
2 Stereo Microphone
3 i.LINK Connector [ i ] ( pg. 49)
4 HDMI Connector [HDMI] ( pg. 35)
5 Component Connector [COMPONENT]
( pg. 35)
6 Video Recording Start/Stop Button [REC]
( pg. 20)
