EN 7
Getting Started
ENGLISH
BATT
Attach the Shoulder Strap
Peel off the pad and thread the
end of the strap through the
eyelet.
Thread the strap through the
buckle, adjust its length, and
use the strap guide to fi x it in
place.
Position the buckle near the
eyelet and reattach the pad.
Tripod Mounting
To attach the camcorder to a tripod, align the direction stud and screw to the mounting socket
and stud hole on the camcorder. Then tighten the screw clockwise.
• Some tripods are not equipped with studs.
Grip Adjustment
Open the pad and make grip adjustments.
• Before making the adjustment, remove any security tags that may be attached to the velcro.
Eyelet
Strap Guide
Buckle
GR-DA30AA_EN.indb 7GR-DA30AA_EN.indb 7 7/9/2007 12:03:14 PM7/9/2007 12:03:14 PM
