JVC GY-HM600U Service Manual

(No.HC047<Rev.001>)1-19
10 OIS Drive Automatic
adjustment
--
(1) Choose ADJ tab -> OIS Drv tab,
press the [START] button.
(2) After pressing the [START] button,
adjust so that the shake of a monitor
screen comes to minimum, while vi-
brating a camera by hand.
(3) It will be completed when displayed
as Complete.
11
INGAIN and
ANALOG-
GAIN
Automatic
adjustment
Mini
studio
White
chart
(1) Prepare an adjustment environ-
ment of 3000K (Mini studio or
something).
(2) Set Record Format to 1920 x 1080,
24p(HQ), if it has not been set so.
Choose SETTING1 tab, input 4 into
the "Video Format Change" column
and then press the [Write] button.
(3) Choose ADJ tab -> Ingain tab,
press the [START] button.
(4) It will be completed when displayed
as Complete.
12
AF Filter ND
1/16
Semiauto
adjustment
Mini
studio
White
chart
(1) Set ND filter to the 1/16 position.
(2) Set Record Format to 1920 x 1080,
60i(HQ) or 1440 x 1080, 60i(HQ), if
it has not been set so. Choose
SETTING1 tab, input 0 into the "Vid-
eo Format Change" column and
then press the [Write] button.
(3) Choose ADJ tab -> AF Filter tab,
press the [START] button of ND 1/
16.
(4) It will be completed when displayed
as Complete.
13
AF Filter ND
1/64
Semiauto
adjustment
Mini
studio
White
chart
(1) Set ND filter to the 1/64 position.
(2) Set Record Format to 1920 x 1080,
60i(HQ) or 1440 x 1080, 60i(HQ), if
it has not been set so. Choose
SETTING1 tab, input 0 into the "Vid-
eo Format Change" column and
then press the [Write] button.
(3) Choose ADJ tab -> AF Filter tab,
press the [START] button of ND 1/
64.
(4) It will be completed when displayed
as Complete.
14
White blem-
ish
Automatic
adjustment
- - (IRIS
CLOSE)
(1) Wait about 30 minutes for pre-heat-
ing the camera.
(2) Set Record Format to 1920 x 1080,
60i(HQ) or 1440 x 1080, 60i(HQ), if
it has not been set so. Choose
SETTING1 tab, input 0 into the "Vid-
eo Format Change" column and
then press the [Write] button.
(3) Choose ADJ tab -> BPD tab, press
the [START].
(4) It will be completed when displayed
as Complete.
No. Adjustment
item
Adjustment
type
Jig Signal Adjustment
point
standard Adjustment
value range
Adjustment
default value
Procedure
