93
HD-ILA Device ProjectionType
Reception Format
Reception Range
Power Source
Power Consumption
Model
NTSC, BTSC System (Multi-Channel Sound)
ATSC Terrestrial, Digital Cable
AC 120V, 60 Hz
215W
110W High-Pressure Mercury Lamp
Screen Size
Speakers 10 cm round X 2
Audio Output Full Range - 10W + 10W
Antenna Terminal
(VHF/UHF,
ATSC/DIGITAL
CABLE IN)
75 ohms (VHF/UHF)(F-type connector)
Illuminated remote control unit x 1 / AA batteries X 2
Two-way Splitter x 1 / RF Cable x 2
Dimensions (inch)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(VARI/FIX)
VARI: More than 0 to 1000mVrms (+2.2dBs)
FIX : 500mVrms (-4dBs) Low impedance (1000 Hz when modulated 100%)
Projection Source
Monitor/Recording
Output
Video: 1Vp-p, 75ohms
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Audio: 250mVrms (-10dBs)
Fs-18dB Low Impedance
Optical Output
Digital Audio
Digital Out (optical) x 1
i.LINK In/Out Jack
TS IN/OUT (4-pin, S400) x 2
IEEE1394 compliant DTCP digital copy protection compatible
56 inch / 142 cm
measured diagonally,
16:9 ratio
52 x 38 1/8 x 17 1/8
131.8 x 96.7 x 43.4
95 / 43
HD-56FC97 HD-61FC97
61 inch / 155 cm
measured diagonally,
16:9 ratio
57 3/8 x 41 1/8 x 18 3/8
145.6 x 104.3 x 46.7
104 / 47
VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper
and Ultra bands (191 channel frequency synthesizer system) at Analog
• Reception of channel A-5 ("95" of the TV set's on-screen cable channel
numbers) is not recommended for your TV set.
VHF 2 to 13, UHF 14 to 69 at ATSC,
CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable
Input 1, 2, 3, 4
Terminal
S (Input 1, 3)
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance
Input 1, 2 Terminal
(component terminal)
1080i / 720p / 480p / 480i
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
DIGITAL-IN
(HDMI input terminal)
HDMI Jack x 2
• The HDMI terminal is not compatible with picture signals of a personal computer.
Video: 1080p / 1080i / 720p / 480p / 480i / VGA
Audio: 2ch PCM, 32 / 44.1 / 48 KHz 16 / 20 / 24 bit
Specifications
Specifications subject to change without notice.
• The open source software is embedded in this product. For more information, please go to:
http://software.jvc.com/opensource/lnx/DP/04_AtscCC/download.html
LCT2067 Eng.indd 93LCT2067 Eng.indd 93 6/21/06 9:32:34 AM6/21/06 9:32:34 AM
