JVC HR-XV1EK Service Manual

Q502
IC503
LTV-817M-VB
Q501
PROTECT
CONTROL
SW.
T501
12
13
4
2
L501
AC IN
D505, D506
D502, D503
6
18
7
COUPLER
13
12
11
10
9
8
7
6
5
4
3
2
1
TUNER 32V
P.FAIL
GND
GND
POWER ON H
UNREG 3.3V
UNREG 3.3V
AT 5.2V
AT 5.2V
AT +13V
MOTOR GND
MOTOR +12V
CP502
REGULATOR
1
2
3
4
5
6
P.CON+5V D
GND
P.CON+5V A
GND
P.CON+9V A
MOTOR GND
CP503
DVD DRIVE
16
9V REG
IC502
KIA7809API
1
3
Q504
Q506
2
P.CON+B
SW.
P.CON SW.
Q505
P.CON5V
SW.
POWER BLOCK DIAGRAM
IC501
KIA431
VOLTAGE
CTL. IC
3
1
NC
2-59 2-60

JVC HR-XV1EK Specifications

Power

AC voltage	230-240 V
frequency	50 Hz
operation power consumption	22 W
standby power consumption	5 W

Audio Characteristics

audio in jack level	500 mV, 50 kΩ
audio out jack level	500 mV, 1 kΩ
SCART-socket audio	500 mV, 50 kΩ
SCART-socket video	1 Vp-p, 75 Ω

DVD Specifications

DVD signal system	PAL
applicable disc types	DVD (12cm, 8cm), CD (12cm, 8cm)
DVD frequency response	4Hz - 22KHz
CD frequency response	4Hz - 20KHz

Weight and Dimensions

weight	4.5 kg
width	430 mm
height	99 mm
depth	310.5 mm
