JVC HR-XV1EK Service Manual

HOW TO IDENTIFY MODELS
How to recognize from the appearance of the model concerned is written below.
Please distinguish from several contents currently printed on the rating label.
CLASS 1
LASER PRODUCT
MODEL NO. HR-XV1EK
7225380017
Serial NO.
from Gemstar Development Corporation.
POWER CONSUMPTION : 22W
VIDEO Plus+ and PlusCode are registered trademarks
230-240V 50Hz
The VIDEO Plus+ system is manufactured under license
of Gemstar Development Corporation.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of
Dolby Laboratories. Confidential unpublished works.
' 1992-1997 Dolby Laboratories. All rights reserved.
Apparatus Claims of U.S. Patent Nos. 4,631,603;4,577,216;4,819,098 and 4,907,093 licensed for limited
viewing uses only.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, lnc.
VICTOR COMPANY OF JAPAN,LTD. ASSEMBLED IN U.K.
DVD PLAYER/ VIDEO CASSETTE RECORDER
WARNING SHOCK HAZARD-DO NOT OPEN.
MODEL NAME
REAR SIDE
RATING LABEL
CLASS 1
LASER PRODUCT
MODEL NO. HR-XV1EK
7225380017
Serial NO.
from Gemstar Development Corporation.
POWER CONSUMPTION : 22W
VIDEO Plus+ and PlusCode are registered trademarks
230-240 V 50 Hz
The VIDEO Plus+ system is manufactured under license
of Gemstar Development Corporation.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of
Dolby Laboratories. Confidential unpublished works.
' 1992-1997 Dolby Laboratories. All rights reserved.
Apparatus Claims of U.S. Patent Nos. 4,631,603;4,577,216;4,819,098 and 4,907,093 licensed for limited
viewing uses only.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, lnc.
VICTOR COMPANY OF JAPAN,LTD. ASSEMBLED IN U.K.
DVD PLAYER/VIDEO CASSETTE RECORDER
WARNING : SHOCK HAZARD-DO NOT OPEN.
HR-XV1EK HR-XV1EU-C
HR-XV1EU-S HR-XV1EU-Y

JVC HR-XV1EK Specifications

Power

AC voltage	230-240 V
frequency	50 Hz
operation power consumption	22 W
standby power consumption	5 W

Audio Characteristics

audio in jack level	500 mV, 50 kΩ
audio out jack level	500 mV, 1 kΩ
SCART-socket audio	500 mV, 50 kΩ
SCART-socket video	1 Vp-p, 75 Ω

DVD Specifications

DVD signal system	PAL
applicable disc types	DVD (12cm, 8cm), CD (12cm, 8cm)
DVD frequency response	4Hz - 22KHz
CD frequency response	4Hz - 20KHz

Weight and Dimensions

weight	4.5 kg
width	430 mm
height	99 mm
depth	310.5 mm
