SCHEMATIC DIAGRAMS
CD RECEIVER
No.MA189SCH
2005/7
KD-G369
COPYRIGHT 2005 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-5 to 6
CD-ROM No.SML200507
KD-G369UR
Area suffix
UR -------------------------- Brazil
