ENGLISH
Graphics Movie demonstration
KeyIn CFM Key-in confirmation
Opening*
1
Opening animation
Ending*
1
Ending animation
UserPict.*
2
User Picture
Clock Hr Hour adjustment
Clock Min Minute adjustment
24H/12H 24 hours or 12 hours
Auto Adj Automatic clock
adjustment
Scroll Scroll mode
Dimmer Dimmer mode
From– To*
3
Dimmer time setting
Contrast Contrast
LCD Type Display type
Font Type Font type
Tag Tag display
*
1
Displayed only after a downloadable file is stored in memory.
*
2
Displayed only after a downloadable file is stored in memory and while selecting “UserPict.” for “Graphics.”
*
3
Displayed only when “Dimmer” is set to “Time Set.”
DISP (display)
Once Auto
Off
Auto Off
On
1 – 10
1
2
Off On
Positive
Negative
Auto
Indications Selectable values/items
Factory-preset See
settings page
Once 48
Auto
50
5
48
Auto
48
1
48
On
48, 49
Time Set
Any time – Any time 18 – 7 50
CLOCK
0 – 23 (1 – 12)
12Hours 24Hours
0 (0:00) 9
00 (0:00) 9
24Hours
9
00 – 59
MOVIE
Int Demo 8, 25, 48
48
Default
User
43
Default
Default User 43Default
See page 48 for details
First stored 44From the stored files
Preferred Setting Mode (PSM) items
The PSM items are grouped into six categories—MOVIE, CLOCK, DISP (display), TUNER, AUDIO,
and COLOR.
Off
On
On 21
OffOn On
EN45-55_KD-LH401[E_EX]f.p65 30/1/04, 5:22 PM46

JVC KD-Lh401 Specifications

Audio Amplifier Specifications

maximum power output front	50 W per channel
maximum power output rear	50 W per channel
continuous power output RMS front	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output RMS rear	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance	4 Ω (4 Ω to 8 Ω allowance)
equalizer control range frequencies	60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz, 12 kHz
equalizer control range level	±10 dB
frequency response	40 Hz to 20 000 Hz
signal-to-noise ratio	70 dB
line-out level/impedance	5.0 V/20 kΩ load (full scale)
output impedance	1 kΩ

CD Player Specifications

operating voltage	DC 14.4 V (11 V to 16 V allowance)
allowable operating temperature	0°C to +40°C
dimensions (W × H × D) installation size	182 mm × 52 mm × 159 mm
dimensions (W × H × D) panel size	188 mm × 58 mm × 12 mm
mass	1.6 kg (excluding accessories)
frequency response	5 Hz to 20 000 Hz
dynamic range	96 dB
signal-to-noise ratio	98 dB
max. bit rate mp3	320 Kbps
max. bit rate wma	192 Kbps

Tuner Specifications

frequency range FM	87.5 MHz to 108.0 MHz
frequency range AM (MW)	522 kHz to 1 620 kHz
frequency range AM (LW)	144 kHz to 279 kHz
usable sensitivity FM	11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM	16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity FM (400 kHz)	65 dB
frequency response FM	40 Hz to 15 000 Hz
stereo separation FM	30 dB
capture ratio FM	1.5 dB
sensitivity MW	20 µV
selectivity MW	35 dB
sensitivity LW	50 µV
