20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Crossover settings
Below are the available setting items for 2-way
crossover and 3-way crossover.
Caution
Select a crossover type according to how the speakers
are connected. (
29
,
30
)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or
low.
SPK SIZE
(speaker size)
Selects according to the connected speaker size for
optimum performance.
•
The frequency and slope settings are
automatically set for the crossover of the selected
speaker.
•
If [
NONE
] is selected for [
TWEETER
] of [
FRONT
], [
REAR
]
and [
SUBWOOFER
] for [
SPK SIZE
], the [
X ‘ OVER
] setting
of the selected speaker is not available.
X ‘ OVER
(crossover)
[
FRQ
]/ [
HPF FRQ
]/ [
LPF FRQ
]:
Adjusts the crossover frequency for the selected
speakers (high pass filter or low pass filter).
•
If [
THROUGH
] is selected, all signals are sent to the
selected speakers.
[
SLOPE
]/ [
HPF SLOPE
]/ [
LPF SLOPE
]
:
Adjusts the crossover slope.
•
Selectable only if a setting other than [
THROUGH
]
is selected for the crossover frequency.
[PHASE]:
Selects the phase of the speaker output to be in
line with the other speaker output.
[
GAIN LEFT
]/ [
GAIN RIGHT
]/ [
GAIN
]:
Adjusts the output volume of the selected speaker.
2-way crossover setting items
SPK SIZE
FRONT SIZE
8CM
/
10CM
/
12CM
/
13CM
/
16CM
/
17CM
/
18CM
/
4×6"
/
5×7"
/
6×8"
/
6×9"
/
7×10"
TWEETER
SML
/
MID
/
LRG
/
NONE
(not connected)
REAR
*
1
8CM
/
10CM
/
12CM
/
13CM
/
16CM
/
17CM
/
18CM
/
4×6"
/
5×7"
/
6×8"
/
6×9"
/
7×10"
/
NONE
(not connected)
SUBWOOFER
*
2
16CM
/
20CM
/
25CM
/
30CM
/
38CM OVER
/
NONE
(not connected)
X ' OVER
TWEETER FRQ
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
5KHZ
/
6.3KHZ
/
8KHZ
/
10KHZ
/
12.5KHZ
GAIN LEFT
–08DB
to
00DB
GAIN RIGHT
–08DB
to
00DB
FRONT HPF FRQ
30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
GAIN
–08DB
to
00DB
REAR HPF
*
1
FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
GAIN
–08DB
to
00DB
SUB.W LPF
*
2
FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
PHASE
REVERSE
(180°)/
NORMAL
(0°)
GAIN –08DB
to
00DB
*
1
Displayed only when [
SPK/PRE
OUT
] is set to [
REAR/REAR
]. (
19
)
*
2
Displayed only when [
SUB.W
] is set to [
ON
]. (
18
)
JS_JVC_KW_R920BT_DB92BT_E_EN_4.indd 20JS_JVC_KW_R920BT_DB92BT_E_EN_4.indd 20 17/11/2015 3:42:53 PM17/11/2015 3:42:53 PM
