11
ENGLISH
1 Screen (touch panel)
2
(Eject) button/Security indicator
•
Adjusts the angle of the front panel. (☞ page 13)
• Displays the disc insert/eject screen. (☞ page 54)
• Displays the SD card insert/eject screen.
(☞ page 61)
• Flashes when the unit is turned off if you have
enabled the security indicator. (☞ page 86)
3
(volume) button
Adjusts the audio volume.
4
button
Displays the screen for the current source.
5
button
Displays the map for the current location.
(☞ page 16)
Turns off/on the screen.[Hold] (☞ page 13)
6
button
Displays the destination menu screen. (☞ page 16)
7 (skip/search) button
8
(source) button
Displays the source screen. (☞ page 17)
Turns off the AV function.[Hold] (☞ page 45)
9 Disc loading slot
p SD card slot
Parts identification
