JVC KW-XC858

1-28 (No.MA089)
 Arrangement of adjusting & test points
Head section view
Cassette mechanism
(Surface)
Azimuth screw
A
(Forward)
Playback head
Tape speed adjust
Motor assembly
Azimuth screw B
(Reverse)
Azimuth screw A
(Forward)
Playback head
Azimuth screw B
(Reverse)
