21
Other convenience functions
Selected Items Setup hint
Setup
OSD Timer The OSD is cleared automatically as per this setting.
But if you select “Never”, the OSD is not cleared
automatically .(Press RETURN to clear.)
5/10/15/20/25/30 Seconds/Never
SCART Input
Auto Factory setting, normally OK.
RGB when RGB is input.
CVBS when Composite is input.
S-Video When S-Video is input.
SCART Output This determines whether the SCART outputs the signal
from the internal tuner or whatever input is shown on the
screen.
TV / Monitor
PC Setup
Auto Adjust H Position, V Position, Phase and Clock are adjusted
automatically as per the input PC video signal.
When PC-input mode was selected and a PC-
signal was input, Auto Adjust will be performed
automatically.
•
H Position To adjust the horizontal placing of the image.
V Position To adjust the vertical placing of the image.
Phase Eliminates the horizontal (PHASE) interfering lines.
Clock Eliminates the vertical (CLOCK) interfering lines.
HDMI Mode
Auto Auto (factory setting), can remain in this mode. Change
not necessary.
PC PC (for PC), if desired.
Video Video (for Video), if desired.
Blue Screen You can set the TV to automatically change to a blue
screen and mute the sound if the signal is weak or
absent.
This option is not available for DTV, PC and Radio
mode.
•
On / Off
Reset TV Setting Press
to enter the Reset TV Setting screen.
Press to select “OK”, then press ENTER. Reset the TV
function will now begin, and this unit will automatically
turn off.
Software Upgrade This option is not available because of service purpose
only.
Version If you press , the μ-com’s software version is displayed.
3IA0951A_EN.indd 213IA0951A_EN.indd 21 11/30/11 10:33:28 AM11/30/11 10:33:28 AM
