ELECTRICAL REPLACEMENT PARTS LIST

R519

X-R803R9103J

RC 10K OHM 1/16W

HPWGJ103T50

! R520 X-R8X2R8334J RC 330K OHM 1/8W 1206W8J0334T5E 1

R522 X-R801R7222J RC 2.2K OHM 1/10W HMWAJ0222T50 1

R523 X-R803R9222F RC 2.2K OHM 1/16W HPWGF222T50 1

R524 X-R803R9911F RC 910 OHM 1/16W HPWGF911T50 1

R525 X-R803R9222F RC 2.2K OHM 1/16W HPWGF222T50 1

! R526 X-R8X2R8334J RC 330K OHM 1/8W 1206W8J0334T5E 1

! R528 X-R8X2R8334J RC 330K OHM 1/8W 1206W8J0334T5E 1

R529 X-R803R9103J RC 10K OHM 1/16W HPWGJ103T50 1

R532 X-R803R9103J RC 10K OHM 1/16W HPWGJ103T50 1

R534 X-R002T4150J RC 15 OHM 1/4W BCS4J0150A10 1

R7001 X-R803R9102J RC 1K OHM 1/16W HPWGJ102T50 1

R7002 X-R803R9223J RC 22K OHM 1/16W HPWG J 223 T50 1

R7003 X-R803R9100J RC 10 OHM 1/16W HPWGJ100T50 1

R7004 X-R801R7101J RC 100 OHM 1/10W HMWAJ0101T50 1

R7005 X-R803R9103F RC 10K OHM 1/16W HPWGF103T50 1

R7008 X-R861R43R9F RC 3.9 OHM 1/4W MCR10EZHFL3R9 1

R7009 X-R861R43R9F RC 3.9 OHM 1/4W MCR10EZHFL3R9 1

R7010 X-R861R43R9F R 3.9 OHM 1/4W MCR10EZHFL3R9 1

R7011 X-R861R43R9F R 3.9 OHM 1/4W MCR10EZHFL3R9 1

R7012 X-R861R43R9F RC 3.9 OHM 1/4W MCR10EZHFL3R9 1

R7013 X-R801R7470J RC 47 OHM 1/10W HMWAJ0470T50 1

R7014 X-R801R7470J RC 47 OHM 1/10W HMWAJ0470T50 1

R7017 X-R803R9473J RC 47K OHM 1/16W HPWG J 473 T50 1

*** CAPACITORS ***

! C501 X-CS0PB04E4K CC 0.015 UF 50V B C0603X7R153K500NT 1

C502

X-E83FHH820D

CE 82 UF 400V

LGJ2G820MELB

C502

X-E83FHH820D

CE 82 UF 400V

LGJ2G820MELB

! C503 X-CS0PCH4L2J CC 330 PF 50V CH C0603C0G331J500NT 1

! C504 X-E8E101102M CE 1000 UF 10V 10ZLH1000MEFC10*12.5 1

! C505 X-CS0PCH411D CC 10 PF 50V CH GRM1882C1H100JA01D 1

! C506 X-P4K12D224K CMPP 0.22 UF 310V LE224-MX-C3.5 1

! C507 X-CE39E0M13M CC 0.001 UF 250V E DE1E3KX102MB4BL01 1

! C508 X-P4K12D104K CMPP 0.1 UF 310V LE104-MX-C3.5 1

! C509 X-CS0PB0415K CC 0.1 UF 50V B C0603X7R104K500NT 1

! C511 X-E8E1T3471M CE 470 UF 25V 25ZLH470MEFCT8 10*12.5 1

! C512 X-E8E2T3221D CE 220 UF 25V 25YXF220MEFCTA 8*11.5 1

C513 X-C03L0R7L2K CC 330 PF 2KV R DEHR33D331KB3B 1

! C514 X-CE39E0MQ2K CC 470 PF 250V E DE1B3KX471KB4BL01 1

C516 X-E8E2U5220D CE 22 UF 50V 50YXF22MEFCT1 5*11 1

C517 X-CS0PB0413K CC 0.001 UF 50V B C0603X7R102K500NT 1

C520 X-E8E2U54R7D CE 4.7 UF 50V 50YXF4.7MEFCT1 5*11 1

C521 X-CS0PB04Q4K CC 0.047 UF 50V B GRM188B11H473KA01D 1

! C522 X-E9E8F3102D CE 1000 UF 25V 25VZLJ1000MKC10*20 1

C523 X-CS0PCH4Q2J CC 470 PF 50V CH C0603CG471J500NT 1

C524 X-CRGTB0413K CC 0.001 UF 50V B UP025B102K-A-BZ 1

C527 X-CRGTB0413K CC 0.001 UF 50V B UP025B102K-A-BZ 1

! C534 X-CE39E0M13M CC 0.001 UF 250V E DE1E3KX102MB4BL01 1

C536 X-CS0PB0413K CC 0.001 UF 50V B C0603X7R102K500NT 1

! C542 X-P416F5223J CMPP 0.022 UF 630V ECWF(L) ECWF6223JLB 1

C7001 X-E9EGU2101M CE 100 UF 16V 16ML101MEFCT5 6.3*7 1

C7002 X-CS0PB0415K CC 0.1 UF 50V B C0603X7R104K500NT 1

C7004 X-CS0PB04E3K CC 0.0015UF 50V B C0603X7R152K500NT 1

C7005 X-CS0PB0415K CC 0.1 UF 50V B C0603X7R104K500NT 1

C7010 X-E8EMU3101D CE 100 UF 25V 25ZLG100MEFC6.3*11 1

C7011 X-CQGTB0415K CC 0.1 UF 50V B UP050B104K-A-BZ 1

C7012 X-CS0PB03Q5K CC 0.47 UF 25V B GRM188B31E474KA75D 1

C7013 X-CS0PB0413K CC 0.001 UF 50V B C0603X7R102K500NT 1

C7015 X-CS0PB04H3K CC 0.0022UF 50V B C0603X7R222K500NT 1

C7016 X-CS0PCH4Q2J CC 470 PF 50V CH C0603CG471J500NT 1

C7017 X-CS0PB0414K CC 0.01 UF 50V B C0603X7R103K500NT 1
