ELECTRICAL REPLACEMENT PARTS LIST
! D504 X-D7KZ385E20 DIODE VARISTA S14K385E2S5M4 1
! D505 X-D4CTN40060 DIODE SILICON 1N4006-A5 1
D506 X-D4JX001F50 DIODE SILICON 1F5 1
! D507 X-D4JXRM11C0 DIODE SILICON ZRM11C 1
! D508 X-D4JXRM11C0 DIODE SILICON ZRM11C 1
! D510 X-D4JXRM11C0 DIODE SILICON ZRM11C 1
! D511 X-D4JX001F50 DIODE SILICON 1F5 1
D512 X-DJBUA12012 DIODE ZENER HZS12NB2 1
! D513 X-D4JXARS010 DIODE SILICON SARS01 1
! D514 X-D28A10A200 DIODE SILICON FCF10A20 1
! D516 X-D1VT001330 DIODE,SILICON 1SS133T-77 1
D517 X-DE7RB1102B DIODE ZENER UDZSNP11B TE-17 1
! D518 X-D4JXRM11C0 DIODE SILICON ZRM11C 1
! D523 X-D28A10A080 DIODE SCHOTTKY BARRIER FCHS10A08 1
! D527 X-DJBUA33012 DIODE ZENER HZS33NB2 1
! D528 X-DJBUA33012 DIODE ZENER HZS33NB2 1
D7003 X-D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 1
*** ICS ***
! IC501 X-ICAJ056400 POWER IC CONTROL FA5640N-D1-TE1 1
! IC502 X-I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT 1
! IC505 X-000220002W PHOTO COUPLER PS2561AL1-1-V(W) 1
IC7001 X-ILYD0887D0 LED DRIVER IC NR887D 1
*** TRANSISTORS ***
! Q501 X-TK1009N900 FET FMV09N90E 1
Q502 X-TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK 1
Q503 X-TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK 1
Q504 X-TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK 1
*** COILS ***
B7001 X-024HT03564 CORE,BEADS W4BRH3.5X6X1.0 1
B7002 X-024HC13914 CORE,BEADS HCB3216KF-391T20 1
! L501 X-029B000187 COIL,LINE FILTER JLB24123 1
L503 X-02167E100K COIL 10 UH TSL0808RA-100K2R 1
L504 X-02167E100K COI 10 UH TSL0808RA-100K2R 1
L7002 X-021D0N220M COIL 22 UH PF13-220-OS 1
*** TRANSFORMERS ***
! T501 X-048128042Z TRANSFORMER,SWITCHING 8128042Z 1
*** JACKS ***
! J502 X-064Q2A0004 JACK,AC CCT2302-0721C 1
*** CONNECTORS ***
CP501 X-069E7G0630 CONNECTOR PCB SIDE 00_6216_016_000_808+ 1
CP7001 X-069EV73030 CONNECTOR PCB SIDE 00_6232_007_006_800+ 1
*** FUSES ***
! F501 X-0805T02501 FUSE SCT 2.5A 1
*** THERMISTOR ***
! TH501 X-DSVD8E4R7M THERMISTOR B57153S0479A001 1
