Product Overview
Main Unit
Front View
Rear View
2. M Button
• Display or exit
main menu.
3. E Button
• Access the menus.
• Executed the “Auto
Adjust Image”
4.
Button
5.
Buttons
6. HDMI socket
7. VGA socket
8. DC socket
1. Power LED
• Illuminates when
the monitor is in
On mode.
• Flash when the
monitor is On but
haven’t received
any signal (Standby
mode).
• Light will go o
when the monitor
is in O mode.
2
3
4
6 7 8
5
1
