1-8 (No.YA712<Rev.002>)
SECTION 3
DISASSEMBLY
3.1 Disassembly Flowchart
This flowchart indicates the disassembly steps for the cabinet
parts, and the CBA in order to gain access to item(s) to be ser-
viced. When reassembling, follow the steps in reverse order.
Bend, route and dress the cables as they were.
3.2 Disassembly Method
NOTE;
(1) Order of steps in procedure. When reassembling, follow
the steps in reverse order. These numbers are also used
as the Identification (location) No. of parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked, un-
locked, released, unplugged, unclamped, or desoldered.
P = Spring, L = Locking Tab, S = Screw, H = Hex Screw,
CN = Connector * = Unhook, Unlock, Release, Unplug,
or Desolder e.g. 2(S-2) = two Screws (S-2), 2(L-2) = two
Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the Table."
[1] Stand
Assembly
[2] Rear Cabinet
[9] Speaker(s)
[8] Speaker
Holder (L,R)
[3] Inverter CBA
[4] Jack CBA
[6] Jack Holder
[7] Digital Main
CBA Unit
[5] Power Supply
CBA
[13] LCD Module
Assembly
[14] Front
Cabinet
[11] IR Sensor
CBA
[10] Junction
CBA
[12] Function
CBA
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1]
Stand
Assembly
D1 4(S-1) ---
[2]
Rear
Cabinet
D1 13(S-2), 2(S-3), 3(S-4) ---
[3]
Inverter
CBA
D2
D4
6(S-5), *CN1001,
*CN1003, *CN1050,
*CN1100, *CN1150,
*CN1200, *CN1900
---
[4] Jack CBA
D2
D4
2(S-6), *CL701B ---
[5]
Power
Supply
CBA
D2
D4
7(S-7), *CN101,
*CN301, *CN302,
*CN801, *CN802
---
[6] Jack Holder D2 2(S-8) ---
[7]
Digital Main
CBA Unit
D2
D4
4(S-9), 2(S-10),
4(S-11), *CN3902,
Shield Box
---
[8]
Speaker
Holder
(L,R)
D3 *Hook ---
[9] Speaker(s) D3 8(S-12) ---
[10]
Junction
CBA
D3
D4
Desolder ---
[11]
IR Sensor
CBA
D3
D4
2(S-13), *CL103C ---
[12]
Function
CBA
D3
D4
2(S-14) ---
[13]
LCD
Module
Assembly
D3 (S-15) ---
[14]
Front
Cabinet
D3 --------------- ---
(1) (2) (3) (4) (5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
