1-2 (No.YA712<Rev.002>)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W × H × D ) 76.0 cm × 56.3 cm × 23.4 cm (30.0" × 22.2" × 9.3") [with stand]
76.0 cm × 51.93 cm × 11.35 cm (30.0" × 20.5" × 4.5") [without stand]
Mass 9.3 kg (20.6 lbs) [with stand]
8.8 kg (19.5 lbs) [without stand]
Power Input AC120 V , 60 Hz
Power Consumption 155 W (Max)
TV RF System
(Analog / Digital)
Analog
Digital
CCIR (M)
ATSC terrestrial / Digital cable
Color System (Analog) NTSC
Stereo System (Analog) BTSC (Multi Channel Sound)
Teletext System (Analog) Closed caption (T1-T4 / CC1-CC4)
TV Receiving Channels
and Frequency (Analog)
VHF Low
VHF High
UHF
CATV
02 ch - 06 ch : 54 MHz - 88 MHz
07 ch - 13 ch : 174 MHz - 216 MHz
14 ch - 69 ch : 470 MHz - 806 MHz
54 MHz - 804 MHz
Low Band : 02 - 06
High Band : 07 - 13
Mid Band : 14 - 22
Super Band : 23 - 36
Hyper Band : 37 - 64
Ultra Band : 65 - 94, 100 - 135
Sub Mid Band : 01, 96 - 99
TV / CATV Total Channel 191 Channels
Intermediate Frequency
(Analog)
Video IF
Sound IF
45.75 MHz
41.25 MHz (4.5 MHz)
Color Sub Carrier Frequency (Analog) 3.58 MHz
LCD Panel 32" class (31.5" Diagonal) wide aspect (16 : 9)
Display Pixels Horizontal : 1366 dots × Vertical : 768 dots (W-XGA)
Audio Power Output 10 W + 10 W
Speaker 1.61" × 2.79", oval type × 2
Antenna Terminal
(VHF/UHF, ATSC / DIGITAL CABLE IN)
F-type connector, 75Ω unbalanced, coaxial × 1
Video / Audio Input
[VIDEO]
S-Video Mini-DIN 4 pin × 1
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω
C: 0.286V (p-p) (Burst signal), 75 Ω
Video 1 V (p-p), Positive (Negative sync.), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), High impedance, RCA pin jack × 2
Video / Audio Input
[COMPONENT]
Component Video
1080i / 720p
480p / 480i
RCA pin jack × 3
Y : 1 V (p-p) (Sync signal: 0.35V(p-p), 3-value sync.), 75 Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1 V (p-p), Positive (Negative sync.), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
Audio 500 mV (rms), High impedance, RCA pin jack × 2
Digital Input Digital(Video/Audio) HDMI 2-row 19pin connector × 3
(Digital-input terminal is not compatible with picture signals of personal computer)
Video: Supported format: 1080i / 720p / 480p / 480i
Audio: 2ch L-PCM, 32 / 44.1 / 48 KHz, 16 / 20 / 24 bit
Analog (Audio) 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
Audio output 500mV(rms) (-4dBs), Low impedance, RCA pin jack × 2
Digital Audio output 500 mV (rms), Coaxial × 1
Remote Control Unit RM-C2150 (AA/R6 battery × 2)
To Next Page
