z A CAM (Conditional Access Module) for watching pay-TV digital channels can be installed. (P. 8)
z DC power can be supplied to the indoor aerial. g
z We may change the design and specifications without notice.
Main unit
Model LT-47DV8BJ LT-42DV8BJ
Broadcasting systems CCIR I
Colour systems
TV broadcast: PAL
External input: PAL, NTSC 3.58/4.43 MHz
Channels and frequencies
z Digital:
E21-E68 (Frequency: 470-854 MHz)
z Analogue:
UNITED KINGDOM: E21-E69 (UHF)
IRELAND: IR A-IR J, E2-E12, E21-E69 (VHF/UHF)
Sound-multiplex systems NICAM (I )
Teletext systems
Digital: MHEG 5 UK profile
Analogue: FLOF (Fastext), WST (World Standard System)
Power requirements AC 220 V - 240 V, 50 Hz
Audio output (Rated power output) 10 W + 10 W
Speakers (4.5 cm x 16 cm) oval x 2 (4.5 cm x 16 cm) oval x 2
Power consumption
[standby]
281 W
[0.5 W]
232 W
[0.5 W]
Screen size
(visible area size measured
diagonally)
118 cm 105 cm
Dimensions (W x H x D: mm)
[without stand]
1121 x 773.7 x 296
[1121 x 726.5 x 129.8]
1007 x 707.2 x 296
[1007 x 660 x 129.1]
Weights
[without stand]
34.0 kg
[30.0 kg]
28.6 kg
[25.6 kg]
Accessories (See “Check accessories”, P. 5)
Terminals / Connectors
Terminal name Terminal type Signal type (IN)
Signal type
(OUT)
Notes
Input /
Output
terminals
EXT-1
Euroconnector x 1
(SCART connector)
Composite video, S-Video,
Analogue RGB
Audio L / R
TV out
EXT-2
Euroconnector x 1
(SCART connector)
Composite video, S-Video,
Analogue RGB
Audio L / R
Dubbing out
“T-V LINK”
compatible
Input
terminals
EXT-3
RCA connectors x 3,
S-VIDEO connector x 1
Composite video, S-Video
Audio L / R
EXT-4 RCA connectors x 5
Analogue component
(576i (625i), 480i (525i),
Progressive: 576p (625p),
480p (525p),
HD: 1080i (1125i), 720p (750p))
Audio L / R
EXT-5
(HDMI-1)
HDMI connector x 3
HDMI
(576i (625i), 480i (525i),
576p (625p), 480p (525p),
720p (750p), 1080i (1125i),
1080p (1125p) / 50 Hz,
1080p (1125p) / 60 Hz)
“HDMI CEC”
compatible
(P. 43)
EXT-6
(HDMI-2)
EXT-7
(HDMI-3)
PC IN D-SUB (15 pins) x 1 Analogue PC signal (P. 42)
Output
terminals
AUDIO OUT RCA connectors x 2 Audio L / R
DIGITAL
AUDIO OUT
OPTICAL connector x 1
Digital audio
(48 kHz, 16 bit
linear PCM /
Dolby Digital)
Headphone
Stereo mini-jack x 1
(3.5 mm in diameter)
Headphone
output
