JVC LX-NZ3BK Service Manual

1-8 (No.PA063<Rev.001>)
Page-7
Page-8
Page-9
Page-10
Item Contents
LAN Version
Change prohibited.
(Only for debug)
Mac Address
LAN Reset
<Press L or R>
USB Mode
DB manual mode
Aperture Position
Aperture Index
Aperture Max
Aperture Min
Aperture Strength
< Press L or R>
Dynamic Black Reset
< Press L or R>
Reset Max/Min Aperture
< Press L or R>
Aperture Position Calibration
< Press L or R>
Waveform ID:
Ballast ID:
Ballast Firmware versionID:
Composer Waverform version
Dust Filter
Item Contents
Lamp Normal (mins) Light source Normal Time
(mins)
Lamp Eco (mins) Light source Eco time (mins)
Lamp VariableLOW (mins) Light source Variable LOW
time (mins)
Lamp VariableHIGH (mins) Light source Variable HIGH
time (mins)
Lamp Lfe Hours Light source Life Hours
Total Hours Light source Total Hours
Power On minutes Power On minutes
Reset All Hours
<Press L or R>
Reset All Hours
Lens Calibration
<Press L or R>
Change prohibited.
(Only for debug)
Led Calibration
<Press L or R>
Mstar Trace
Item Parameter
CCI calibration
Change prohibited.
(Only for debug)
CCI enable
Cal ramp
subframe O strb
sensor real time value R
sensor real time value G
sensor real time value B
sensor cal value R
sensor cal value G
sensor cal value B
measured Rx
measured Gx
measured Bx
measured Ry
measured Gy
measured By
measured R lurm
measured G lurm
measured B lurm
Item Parameter
system no.
Change prohibited.
(Only for debug)
duty index
sensor delay
sensor duration R
sensor duration G
sensor duration B
SSI modeule
R strobe
G strobe
B strobe
Y strobe
C strobe
M strobe
W strobe
CCI current adjust mode for WP
AutoKeystoneCalEnable

JVC LX-NZ3BK Specifications

General

Type	laser
Color	black
Throw Type	standard throw
TV Tuner	no
Portable	fixed
Noise Level	29 decibels
Color Brightness	3000 lumens
White Brightness	3000 lumens
Resolution	4k (2160p)
Native Resolution	1920 x 1080
Contrast Ratio	infinity:1 dynamic contrast ratio
Aspect Ratio	16:9
Throw Ratio Range	1.36-2.18
Response Time	58 milliseconds
HDR	yes
HDR Format	hdr 10, hybrid log-gamma (hlg)
3 Chip Technology	no
3D	no
Minimum Screen Size	60 inches
Maximum Screen Size	200 inches
Focus Adjustment	manual
Optical Zoom	1.6x
HDMI Ports	2
HDMI 2.2 Ports	1
HDMI ARC Ports	no
USB Ports	0
RS-232 Port	1
Video Input	hdmi
Inputs	hdmi, usb type a, svga, serial, 3.5mm audio
Remote Control	yes

Weight and Dimensions

Depth	13 1/2 inches
Height	5 3/4 inches
Width	15 7/8 inches
Net Weight	13.89 pounds
