JVC MX-K35V Service Manual

MX-K35V
1-7
Fig.5
Removing the top cover
(See Fig.5 and 6)
1.
2.
3.
Remove the two screws C and four screws D that
retain the top cover from the rear of the body.
Remove the four screws E retain the top cover from
the two sides of the body.
Remove the top cover from the body by lifting it
toward the rear.
Fig.6
C
DD
Top cover
Front panel assembly
E
E
