3-27
Head amplifier & Cassette switch board
Block No. [0][9]
R662 NRSA02J-101X MG RESISTOR 100 Ω 1/10W J
R664 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R665 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R666 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R667 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R668 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R669 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R671 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R672 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R673 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R674 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R675 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R676 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R678 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R679 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R681 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R682 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R801 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R802 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R803 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R805 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R806 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R807 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R811 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R814 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R815 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R816 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R818 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R830 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R831 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R832 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R833 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R834 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R835 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R836 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R837 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R838 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R839 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R840 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R841 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R842 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R843 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R844 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R845 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R846 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R847 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R848 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
CN601 QGF1008F2-16 CONNECTOR FFC/FPC (1-16)
CN603 QGA2501F1-02 CONNECTOR W-B (1-2)
CN651 QGF1036F2-17 CONNECTOR FFC/FPC (1-17)
FW602 QJK004-060601-E SIN CL C-B WIRE
K251 NQR0007-002X FERRITE BEADS
K252 NQR0007-002X FERRITE BEADS
K254 NQR0007-002X FERRITE BEADS
K651 QQR0621-001Z FERRITE BEADS
K654 NQR0007-002X FERRITE BEADS
X251 QAX0684-001Z C RESONATOR
X651 NAX0476-001X CRYSTAL
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3/Z1/ PHOTO SENSER
IC31 BA3126N IC
IC32 AN7317 IC
IC33 BU4094BCF-X IC
Q101 DTC114TKA-X TRANSISTOR
Q102 DTC114TKA-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q201 DTC114TKA-X TRANSISTOR
Q202 DTC114TKA-X TRANSISTOR
Q301 DTA144EKA-X DIGI TRANSISTOR
Q302 2SC2001/K/-T TRANSISTOR
Q303 2SC2001/K/-T TRANSISTOR
Q304 2SC2001/LK/-T TRANSISTOR
Q305 2SC2001/LK/-T TRANSISTOR
Q306 2SC2412K/RS/-X TRANSISTOR
Q307 2SC2412K/RS/-X TRANSISTOR
Q308 2SC2412K/RS/-X TRANSISTOR
Q309 2SC2412K/RS/-X TRANSISTOR
Q321 DTC144EKA-X DIGI TRANSISTOR
Q323 2SC2412K/RS/-X TRANSISTOR
Q371 2SA952/LK/-T TRANSISTOR
Q372 DTC124EKA-X DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 2SC2412K/RS/-X TRANSISTOR
D1 1SR139-400-T2 SI DIODE
D301 MA152WA-X DIODE
D309 MA704A-X S.K.DIODE
D375 HZM5.1NB2-X Z DIODE
C101 NCS21HJ-821X C CAPACITOR 820pF 50V J
C102 NCS21HJ-221X C CAPACITOR 220pF 50V J
C103 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C104 NCB21HK-333X C CAPACITOR 0.033uF 50V K
C105 NCB21HK-222X C CAPACITOR 2200pF 50V K
C106 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C107 NCS21HJ-561X C CAPACITOR 560pF 50V J
C108 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 NCB21HK-682X C CAPACITOR 6800pF 50V K
C111 NCB21HK-122X C CAPACITOR 1200pF 50V K
C112 NCB21EK-683X C CAPACITOR 0.068uF 25V K
C113 NCB21HK-222X C CAPACITOR 2200pF 50V K
C121 NCS21HJ-331X C CAPACITOR 330pF 50V J
C201 NCS21HJ-821X C CAPACITOR 820pF 50V J
C202 NCS21HJ-221X C CAPACITOR 220pF 50V J
C203 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C204 NCB21HK-333X C CAPACITOR 0.033uF 50V K
C205 NCB21HK-222X C CAPACITOR 2200pF 50V K
C206 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C207 NCS21HJ-561X C CAPACITOR 560pF 50V J
C208 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 NCB21HK-682X C CAPACITOR 6800pF 50V K
C211 NCB21HK-122X C CAPACITOR 1200pF 50V K
C212 NCB21EK-683X C CAPACITOR 0.068uF 25V K
C213 NCB21HK-222X C CAPACITOR 2200pF 50V K
C221 NCS21HJ-331X C CAPACITOR 330pF 50V J
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C302 NCB21HK-393X C CAPACITOR 0.039uF 50V K
C303 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C304 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C305 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C306 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C307 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C308 NCB21HK-562X C CAPACITOR 5600pF 50V K
C309 NCB21HK-562X C CAPACITOR 5600pF 50V K
C310 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C311 NCB21HK-682X C CAPACITOR 6800pF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C315 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C316 QFG32AJ-103Z PP CAPACITOR 0.01uF 100V J
C318 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C319 QFG32AJ-821Z PP CAPACITOR 820pF 100V J
C321 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C322 QFG32AJ-152Z PP CAPACITOR 1500pF 100V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C351 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C375 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C391 NCB31HK-681X C CAPACITOR 680pF 50V K
 Symbol No. Part No. Part Name Description Local
