• Pin function
Pin No. Symbol I/O Function
1 OUT4 O PORT output 4
2 OUT3 O PORT output 3
3 OUT2 O PORT output 2
4 OUT1 O PORT output 1
5 AVDD - Analog positive power supply terminal
6 SWin I Volume input
7 GNDS - Ground terminal
8 SRin I Volume input
9 SLin I Volume input
10 GNDC - Ground terminal
11 Cin I Volume input
12 GNDR - Ground terminal
13 Rin I Tone input
14 GNDL - Ground terminal
15 Lin I Tone input
16 BYPASSR I R channel volume input
17 BYPASSL I L channel volume input
18 LTRE I Tone treble frequency adjusting terminal
19 LBASS3 I Tone bass frequency adjusting terminal
20 LBASS2 I Tone bass frequency adjusting terminal
21 LBASS1 I Tone bass frequency adjusting terminal
22 RBASS1 I Tone bass frequency adjusting terminal
23 RBASS2 I Tone bass frequency adjusting terminal
24 RBASS3 I Tone bass frequency adjusting terminal
25 RTRE I Tone treble frequency adjusting terminal
26 CR2 O Tone output terminal
27 CR1 I R channel volume input
28 CL2 O Tone output terminal
29 CL1 I L channel volume input
30 AVSS - Analog negative power supply terminal
31 Lout O L channel output
32 Rout O R channel output
33 Cout O Volume output
34 SLout O Volume output
35 SRout O Volume output
36 SWout O Volume output
37 AGND - Analog ground terminal
38 DGND - Digital ground terminal
39 LATCH I Latch input terminal
40 DATA I Data input terminal
41 CLK I Data transfer clock input terminal
42 DVDD - Digital power supply terminal
