Specifications
Amplifier
Output Power
At Stereo operation:
Front channels:
120 W per channel, min. RMS,
driven into 8
Ω, 20 Hz to 20 kHz with
no more than 0.02% total harmonic
distortion.
120 W per channel, min. RMS, driven into 4 Ω,
20 Hz to 20 kHz with no more than 0.08% total
harmonic distortion.
At Surround operation:
Front channels: 100 W per channel, min. RMS, driven into 8 Ω
at 1 kHz with no more than 0.8% total harmonic
distortion.
Center channel:100 W, min. RMS, driven into 8 Ω at 1 kHz,
with no more than 0.8% total harmonic
distortion.
Rear channels: 100 W per channel, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8% total
harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
PHONO (MM): 2.5 mV/47 kΩ
DVD, VCR 1, VCR 2, VIDEO, TV SOUND/DBS, CD, CDR, TAPE/MD:
200 mV/47 kΩ
Audio Input (DIGITAL IN)* :
Coaxial: DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω
Optical: DIGITAL 2 (CD), DIGITAL 3 (TV), DIGITAL 4 (CDR):
–21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS
Digital Surround (with sampling frequency
— 32 kHz, 44.1 kHz, 48 kHz).
USB:Revision 1.0, Full-speed (with sampling frequency
— 32 kHz, 44.1 kHz, 48 kHz)
Audio Output Level:
SUB ROOM PRE OUT: 200 mV
Recording Output Level: TAPE/MD, VCR 1, VCR 2, CDR: 200 mV
Digital output: Optical: DIGITAL OUTPUT
Signal wave length: 660 nm
Output level: –21 dBm to –15 dBm
Signal-to-Noise Ratio (’66 IHF/’78 IHF):
PHONO: 70 dB/78 dB (at REC OUT)
DVD, VCR 1, VCR 2, VIDEO, TV SOUND/DBS, CD, CDR, TAPE/MD:
92 dB/80 dB (Line Direct On)
Frequency Response (8 Ω):
PHONO: 20 Hz to 20 kHz (±1 dB)
VCR 1, VCR 2, VIDEO, TV SOUND/DBS, CD, CDR, TAPE/MD,
DVD CENTER, DVD REAR, DVD FRONT
:
20 Hz to 20 kHz (±1 dB, –3 dB)
USB
:
20 Hz to 20 kHz (±1 dB, –3 dB)
RIAA Phono Equalization: ±1.0 dB (20 Hz to 20 kHz)
Bass boost (Volume control at –30 dB): +6 ±1.0 dB at 100 Hz
Video
Video Input Sensitivity/Impedance:
Composite video: DVD, VCR 1, VCR 2, VIDEO,
TV SOUND/DBS: 1 V(p-p)/75 Ω
S-video: DVD, VCR 1, VCR 2, VIDEO, TV SOUND/DBS:
(Y: luminance): 1 V(p-p)/75Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component: DVD, DBS
(Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): ±0.7 V/75 Ω
Video Output Level:
Composite video: VCR 1, VCR 2, MONITOR OUT:
1 V(p-p)/75 Ω
S-video: VCR 1, VCR 2, MONITOR OUT:
(Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component: MONITOR OUT
(Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): ±0.7 V/75 Ω
Synchronization: Negative
Signal-to-Noise Ratio: 45 dB
On-Screen Color System: NTSC
FM tuner (IHF)
Tuning Range: 87.5 MHz to 108.0 MHz
Usable Sensitivity: Monaural:12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity:
Monaural: 21.3 dBf (3.2 µV/75 Ω)
Stereo: 41.3 dBf (31.5 µV/75 Ω)
Signal-to-Noise Ratio (IHF-A weighted):
Monaural: 78 dB at 85 dBf
Stereo: 73 dB at 85 dBf
Total Harmonic Distortion:
Monaural: 0.4% at 1 kHz
Stereo: 0.6% at 1 kHz
Stereo Separation at REC OUT: 35 dB at 1 kHz
Alternate Channel Selectivity: 45 dB: (±400 kHz)
Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM tuner
Tuning Range: 530 kHz to 1 710 kHz
Usable Sensitivity: Loop antenna: 400 µV/m
Signal-to-Noise Ratio: 50 dB (100 mV/m)
General
Power Requirements: AC 120V , 60 Hz
Power Consumption: 320 W/440 VA (at operation)
2 watts (in standby mode)
Dimensions (W x H x D): 435 mm x 156.5 mm x 425.1 mm
(17
3
/16 in. x 6
3
/16 in. x 16
3
/4 in.)
Mass: 11.6 kg (25.6 lbs)
Designs & specifications are subject to change without notice.
