JVC RX-9010VBK Service Manual

RX-9010VBK
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
Item
Parts number Parts name Area
Remarks
A
C 701 QTE1V06-106Z E CAPACITOR
C 702 QTE1V06-106Z E CAPACITOR
C 703 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C 704 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C 705 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C 706 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C 707 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 708 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 709 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 710 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 711 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 712 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 713 QCS31HJ-680Z C CAPACITOR 68PF 5% 50V
C 714 QCS31HJ-680Z C CAPACITOR 68PF 5% 50V
C 715 QCS31HJ-680Z C CAPACITOR 68PF 5% 50V
C 716 QCS31HJ-680Z C CAPACITOR 68PF 5% 50V
C 717 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V
C 718 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V
C 719 QFLC1HJ-472Z M CAPACITOR 4700PF 5% 50V
C 720 QFLC1HJ-472Z M CAPACITOR 4700PF 5% 50V
C 741 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C 742 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C 745 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C 746 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C 751 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 752 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 753 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 754 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 791 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 792 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 793 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 794 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 795 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 796 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
CN711 QGB2510K1-14 CONNECTOR
CN712 QGB2510K1-14 CONNECTOR
CN713 QGB2510K1-10 CONNECTOR
CN715 QGB2510K1-12 CONNECTOR
CN716 QGB2510K1-12 CONNECTOR
CN722 QGA2501F1-02 CONNECTOR
C1701 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1702 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C1703 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C1704 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1705 QCS31HJ-5R0Z C CAPACITOR 5.0PF 5% 50V
C1711 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C1712 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C1713 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1715 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1741 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1743 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1751 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1752 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1761 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1762 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1791 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1801 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1802 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1803 QCS31HJ-181Z C CAPACITOR 180PF 5% 50V
C1804 QCS31HJ-181Z C CAPACITOR 180PF 5% 50V
C1805 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C1806 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C1807 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1808 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1809 QCS31HJ-5R0Z C CAPACITOR 5.0PF 5% 50V
C1810 QCS31HJ-5R0Z C CAPACITOR 5.0PF 5% 50V
C1811 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C1812 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C1813 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C1814 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C1815 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1816 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1817 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1818 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1841 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1842 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1843 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1844 QETN2AM-476Z E CAPACITOR 47MF 20% 100V
C1851 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1852 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1853 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1854 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C1861 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1862 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1863 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1864 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C1891 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1892 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
D 701 1SS133-T2 SI DIODE
D 702 1SS133-T2 SI DIODE
D 703 1SS133-T2 SI DIODE
D 704 1SS133-T2 SI DIODE
D 771 1SS133-T2 SI DIODE
D 772 1SS133-T2 SI DIODE
D 773 1SS133-T2 SI DIODE
D 774 1SS133-T2 SI DIODE
D 791 1SS133-T2 SI DIODE
D 792 1SS133-T2 SI DIODE
D1701 1SS133-T2 SI DIODE
D1771 1SS133-T2 SI DIODE
D1772 1SS133-T2 SI DIODE
D1791 1SS133-T2 SI DIODE
D1801 1SS133-T2 SI DIODE
D1802 1SS133-T2 SI DIODE
D1871 1SS133-T2 SI DIODE
D1872 1SS133-T2 SI DIODE
D1873 1SS133-T2 SI DIODE
D1874 1SS133-T2 SI DIODE
D1891 1SS133-T2 SI DIODE
D1892 1SS133-T2 SI DIODE
L 791 QQLZ003-1R0 INDUCTOR
L 792 QQLZ003-1R0 INDUCTOR
L1761 QQLZ005-R45 INDUCTOR
L1861 QQLZ005-R45 INDUCTOR
L1862 QQLZ005-R45 INDUCTOR
Q
701 2SC2240-BL/AB/T TRANSISTOR
Q
702 2SC2240-BL/AB/T TRANSISTOR
Q
703 2SC2240-BL/AB/T TRANSISTOR
Q
704 2SC2240-BL/AB/T TRANSISTOR
Q
705 KTA1268/GL/-T TRANSISTOR
Q
706 KTA1268/GL/-T TRANSISTOR
Q
707 KTA1268/GL/-T TRANSISTOR
Q
708 KTA1268/GL/-T TRANSISTOR
Q
709 KTA1268/GL/-T TRANSISTOR
Q
710 KTA1268/GL/-T TRANSISTOR
Q
711 KTC3200/GL/-T TRANSISTOR
(Power board)
