JVC RX-DP20VBK Service Manual

3-25
Audio board
Block No. [0][7][0][0]
R7736 QRV12DF-1000 CMF RESISTOR 100 Ω 1/2W F
R7737 QRV12DF-1000 CMF RESISTOR 100 Ω 1/2W F
R7738 QRV12DF-1000 CMF RESISTOR 100 Ω 1/2W F
R7739 QRV12DF-1000 CMF RESISTOR 100 Ω 1/2W F
R7740 QRV12DF-1000 CMF RESISTOR 100 Ω 1/2W F
R7751 QRZ9005-470X FUSI RESISTOR 47
Ω
R7752 QRZ9005-470X FUSI RESISTOR 47 Ω
R7753 QRZ9005-470X FUSI RESISTOR 47 Ω
R7754 QRZ9005-470X FUSI RESISTOR 47 Ω
R7755 QRZ9005-470X FUSI RESISTOR 47 Ω
R7756 QRZ9005-470X FUSI RESISTOR 47 Ω
R7757 QRZ9005-470X FUSI RESISTOR 47 Ω
R7758 QRZ9005-470X FUSI RESISTOR 47 Ω
CN731 QGA2501F1-03 CONNECTOR W-B (1-3)
CN732 QGA2501F1-03 CONNECTOR W-B (1-3)
CN733 QGA2501F1-03 CONNECTOR W-B (1-3)
CN734 QGA2501F1-03 CONNECTOR W-B (1-3)
CN735 QGA2501F1-03 CONNECTOR W-B (1-3)
CN736 QGA2501F1-03 CONNECTOR W-B (1-3)
CN737 QGA2501F1-03 CONNECTOR W-B (1-3)
J701 QNN0510-001 PIN JACK 6PIN
J702 QNN0511-001 PIN JACK
WR700 QJK016-143504 14P PLUG ASSY
 Symbol No. Part No. Part Name Description Local
IC501 TC74HC238AF-X IC
IC502 UPC1830GT-XE IC
IC503 NJM2580M-X IC Video amp.
IC631 NJM5532M-D-XE IC
IC632 NJM5532M-D-XE IC
IC633 NJM5532M-D-XE IC
IC634 MN35505-X IC DAC
IC635 JCV8006 IC
IC636 NJM4580E-W IC Ope amp.
IC637 NJM5532M-D-XE IC
IC638 NJM5532M-D-XE IC
IC639 MN35505-X IC DAC
IC640 JCV8006 IC
IC641 NJM4580E-W IC Ope amp.
IC642 NJM4580E-W IC Ope amp.
IC643 NJM5532M-D-XE IC
IC644 MN35505-X IC DAC
IC645 JCV8006 IC
IC646 NJM4580E-W IC Ope amp.
IC647 NJM4580E-W IC Ope amp.
IC648 NJM5532M-D-XE IC
IC649 MN35505-X IC DAC
IC650 JCV8006 IC
IC651 SN74LV157APW-X IC
IC654 NJM2121M-X IC Op amp.
IC655 NJM4580E-W IC Ope amp.
IC656 NJM4580E-W IC Ope amp.
IC657 CS5361-KS-X IC
IC658 CS5333-KZ-X IC
IC659 CS5333-KZ-X IC
IC660 SN74LVC1GU04K-X IC
IC686 NJM4580E-W IC Ope amp.
IC687 NJM5532M-D-XE IC
IC694 BA033FP-X IC Regulator
IC695 BA033FP-X IC Regulator
IC696 BA033FP-X IC Regulator
Q501 KRC105M-T DIGI TRANSISTOR
Q502 KRC105M-T DIGI TRANSISTOR
Q503 KRC105M-T DIGI TRANSISTOR
Q504 KRC105M-T DIGI TRANSISTOR
Q505 KRC105M-T DIGI TRANSISTOR
Q506 KRC105M-T DIGI TRANSISTOR
Q507 2SA1037AK/RS/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q581 KRC105M-T DIGI TRANSISTOR
Q582 KRC105M-T DIGI TRANSISTOR
Q3105 DTA114YE-X TRANSISTOR
Q3107 2SD1328/ST/-X TRANSISTOR
Q3108 2SD1328/ST/-X TRANSISTOR
Q3161 2SC2412K/RS/-X TRANSISTOR
Q3162 2SC2412K/RS/-X TRANSISTOR
Q3163 DTA114YE-X TRANSISTOR
Q3203 2SC2412K/RS/-X TRANSISTOR
Q3207 2SD1328/ST/-X TRANSISTOR
Q3208 2SD1328/ST/-X TRANSISTOR
Q3261 2SC2412K/RS/-X TRANSISTOR
Q3263 DTA114YE-X TRANSISTOR
Q3265 DTA114YE-X TRANSISTOR
Q3266 2SD1328/ST/-X TRANSISTOR
Q3291 DTC114YE-X TRANSISTOR
Q3301 DTA114YE-X TRANSISTOR
Q3303 2SC2412K/RS/-X TRANSISTOR
Q3304 2SC2412K/RS/-X TRANSISTOR
Q3307 2SD1328/ST/-X TRANSISTOR
Q3308 2SD1328/ST/-X TRANSISTOR
Q3361 2SC2412K/RS/-X TRANSISTOR
Q3362 2SC2412K/RS/-X TRANSISTOR
Q3363 DTA114YE-X TRANSISTOR
Q3403 2SC2412K/RS/-X TRANSISTOR
Q3404 2SC2412K/RS/-X TRANSISTOR
Q3407 2SD1328/ST/-X TRANSISTOR
Q3408 2SD1328/ST/-X TRANSISTOR
Q3461 2SC2412K/RS/-X TRANSISTOR
Q3462 2SC2412K/RS/-X TRANSISTOR
Q3463 DTA114YE-X TRANSISTOR
D501 1SS355-X SI DIODE
D502 1SS355-X SI DIODE
D503 1SS355-X SI DIODE
D504 1SS355-X SI DIODE
D505 1SS355-X SI DIODE
D506 1SS355-X SI DIODE
D581 1SS355-X SI DIODE
D582 1SS355-X SI DIODE
C501 QETN1CM-476Z E CAPACITOR 47uF 16V M
C502 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C503 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C504 QETN1HM-225Z E CAPACITOR 2 2uF 50V M
C505 QETN1HM-225Z E CAPACITOR 2 2uF 50V M
C506 QETN1AM-227Z E CAPACITOR 220uF 10V M
C507 QETN1AM-227Z E CAPACITOR 220uF 10V M
C508 QETN1AM-477Z E CAPACITOR 470uF 10V M
C509 QETN1AM-107Z E CAPACITOR 100uF 10V M
C510 QETN1EM-476Z E CAPACITOR 47uF 25V M
C511 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C512 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C513 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1501 NCS31HJ-681X C CAPACITOR 680pF 50V J
C1502 NCS31HJ-561X C CAPACITOR 560pF 50V J
C1503 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1504 QETN1HM-225Z E CAPACITOR 2 2uF 50V M
C1505 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1506 QETN1EM-226Z E CAPACITOR 22uF 25V M
C1507 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1508 QETN1EM-226Z E CAPACITOR 22uF 25V M
C1509 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1510 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1511 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1512 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1513 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1514 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1515 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1516 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1517 QETN1CM-226Z E CAPACITOR 22uF 16V M
C1518 NCF21CZ-104X C CAPACITOR 0.1uF 16V Z
C1519 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1520 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C1521 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C1522 NCF21HZ-103X C CAPACITOR 0 01uF 50V Z
C1523 NCS31HJ-100X C CAPACITOR 10pF 50V J
C1524 NCS31HJ-100X C CAPACITOR 10pF 50V J
 Symbol No. Part No. Part Name Description Local
