JVC RX-DP20VBK Service Manual

3-21
DSP board
Block No. [0][5][0][0]
J1211 QNS0073-001 JACK
J1212 QNS0073-001 JACK
J1213 QNS0077-001 3.5 JACK
JS961 QSW0867-001 SWITCH
K472 QQR0779-001Z COIL
K1035 QQR1183-001Z FERRITE BEADS
S1001 QSW0683-001Z PUSH SW
S1002 QSW0683-001Z PUSH SW
S1003 QSW0683-001Z PUSH SW
S1004 QSW0683-001Z PUSH SW
S1005 QSW0683-001Z PUSH SW
S1006 QSW0683-001Z PUSH SW
S1007 QSW0683-001Z PUSH SW
S1022 QSW0683-001Z PUSH SW
S1023 QSW0683-001Z PUSH SW
S1024 QSW0683-001Z PUSH SW
S1025 QSW0683-001Z PUSH SW
S1026 QSW0683-001Z PUSH SW
S1027 QSW0683-001Z PUSH SW
S1028 QSW0683-001Z PUSH SW
S1029 QSW0683-001Z PUSH SW
S1030 QSW0683-001Z PUSH SW
S1031 QSW0683-001Z PUSH SW
S1032 QSW0683-001Z PUSH SW
S1033 QSW0683-001Z PUSH SW
S1034 QSW0683-001Z PUSH SW
S1035 QSW0683-001Z PUSH SW
S1041 QSW0683-001Z PUSH SW
S1042 QSW0683-001Z PUSH SW
S1043 QSW0683-001Z PUSH SW
S1044 QSW0683-001Z PUSH SW
S1051 QSW0851-001 SWITCH
S1052 QSW0851-001 SWITCH
TF1 QMR0010-001 TH PROTECTOR
TF2 QMR0008-001 TH PROTECTOR
TW471 QUB220-14HPDM TER.WIRE
UN634 GP1FM313RZ OPT RECEIVER
WR64 QJK030-033403 SIN CR C-B WIRE
WR65 QJK030-023002 SIN CR C-B WIRE
WR301 QJK017-030803 SIN CR C-B WIRE
WR961 QJK030-084803 SIN CR C-B WIRE
WR962 QJK030-082003 SIN CR C-B WIRE
WR966 QJK016-092004 SIN CR C-B WIRE
WR967 QJK016-082402 SIN CR C-B WIRE
WR968 QJK016-094403 SIN CR C-B WIRE
WR970 QJK016-090802 SIN CR C-B WIRE
WR972 QJK016-021002 SIN CR C-B WIRE
WR977 QJK030-042004 SIN CR C-B WIRE
WR984 QJK016-101104 SIN CR C-B WIRE
WR986 QJK016-061102 SIN CR C-B WIRE
X1001 QAX0246-001Z C RESONATOR 8.00MHz
X1002 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC481 TC9090AN IC
IC482 UPC1862GS-X IC
IC661 TMX320DA610P225 IC
IC662 SST39VF160-7CEK IC (FLASH)
16 Mbit multi-
purpose flash
memory
IC663 HY57641620HGT7 IC
IC671 UPD78F4216AC924 IC
IC673 AK4112BVF-X IC(MICRO C ROM)
Digital audio
receiver
IC674 SN74LV126APW-X IC
IC675 CS8405A-CS-X IC
IC676 SN74LV157APW-X IC
IC677 SN74AHC2G74T-X IC
IC678 SN74LV74APW-X IC
IC681 SN74LV157APW-X IC
IC690 PQ012FZ01Z-X IC
 Symbol No. Part No. Part Name Description Local
IC691 BA033FP-X IC Regulator
IC692 BA033FP-X IC Regulator
IC693 BA033FP-X IC Regulator
IC700 SN74LVC1G04K-X IC
IC801 TC5081BP IC
IC802 SN74LVC1GU04K-X IC
IC803 SN74AHC2G74T-X IC
IC804 TC3W03FU-X IC
IC805 SN74LV393APW-X IC
IC806 SN74AHC2G74T-X IC
IC807 SN74LVC1G04K-X IC
IC808 SN74AHCT32PW-X IC(DIGITAL)
IC809 SN74LV74APW-X IC
IC810 SN74LVC1G04K-X IC
IC811 SN74LV157APW-X IC
IC812 SN74LV74APW-X IC
IC814 SN74LV126APW-X IC
IC815 SN74LV393APW-X IC
IC816 SN74LV126APW-X IC
IC817 SN74LVC2G241T-X IC
IC818 SN74LV126APW-X IC
IC819 SN74LV393APW-X IC
IC820 SN74LV126APW-X IC
IC821 SN74AHC2G74T-X IC
IC822 SN74LVC1G04K-X IC
IC831 PQ20VZ11-X IC Regulator
Q3651 DTC114YE-X TRANSISTOR
Q3921 DTC114YE-X TRANSISTOR
Q3922 DTC114YE-X TRANSISTOR
Q4801 2SC2412K/RS/-X TRANSISTOR
Q4802 2SC2412K/RS/-X TRANSISTOR
Q4803 2SC2412K/RS/-X TRANSISTOR
Q4804 2SA1037AK/RS/-X TRANSISTOR
Q4805 2SC2412K/RS/-X TRANSISTOR
Q4806 2SA1037AK/RS/-X TRANSISTOR
Q4807 2SC2412K/RS/-X TRANSISTOR
Q4808 2SA1037AK/RS/-X TRANSISTOR
D3601 SVC343-X VARI CAP
D3602 SVC343-X VARI CAP
D3604 1SS355-X SI DIODE
C3501 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C3502 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C3503 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3504 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3505 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3506 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3507 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3508 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3509 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3510 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3511 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3512 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3513 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3514 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3515 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3516 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3517 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3518 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3519 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3520 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3521 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3522 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3531 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C3532 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C3533 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3534 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3535 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3536 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3537 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3538 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3539 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3540 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3541 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3542 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C3543 NCB31HK-103X C CAPACITOR 0 01uF 50V K
 Symbol No. Part No. Part Name Description Local
