JVC RX-DP20VBK Service Manual

3-30
K3282 NQR0229-001X FERRITE BEADS
K3283 NQR0229-001X FERRITE BEADS
K3284 NQR0229-001X FERRITE BEADS
K3381 NQR0229-001X FERRITE BEADS
K3382 NQR0229-001X FERRITE BEADS
K3383 NQR0229-001X FERRITE BEADS
K3384 NQR0229-001X FERRITE BEADS
K3481 NQR0229-001X FERRITE BEADS
K3482 NQR0229-001X FERRITE BEADS
K3483 NQR0229-001X FERRITE BEADS
K3484 NQR0229-001X FERRITE BEADS
LC635 NQR0450-001X EMI FILTER 0.022uF 50V M
LC640 NQR0450-001X EMI FILTER 0.022uF 50V M
LC645 NQR0450-001X EMI FILTER 0.022uF 50V M
LC650 NQR0450-001X EMI FILTER 0.022uF 50V M
RY501 QSK0150-001 RELAY
RY502 QSK0150-001 RELAY
RY503 QSK0150-001 RELAY
RY504 QSK0150-001 RELAY
RY505 QSK0150-001 RELAY
RY506 QSK0150-001 RELAY
RY581 QSK0150-001 RELAY
RY582 QSK0150-001 RELAY
S1009 NSW0059-001X TACT SW
S1010 NSW0059-001X TACT SW
S1011 NSW0059-001X TACT SW
S1012 NSW0059-001X TACT SW
S1013 NSW0059-001X TACT SW
S1014 NSW0059-001X TACT SW
S1016 NSW0059-001X TACT SW
S1017 NSW0059-001X TACT SW
S1018 NSW0059-001X TACT SW
S1019 NSW0059-001X TACT SW
S1020 NSW0059-001X TACT SW
S1021 NSW0059-001X TACT SW
WR632 QJK016-124600 S N CR C-B WIRE
X501 QAX0529-001 C RESONATOR 500.00kHz
X502 QAX0703-001Z CRYSTAL 3.579545MHz
X3001 NAX0435-001X CRYSTAL 24 576MHz
 Symbol No. Part No. Part Name Description Local

JVC RX-DP20VBK Specifications

General

Brand	JVC
Model	RX-DP20VBK
Category	Receiver
Language	English
