JVC RX-DP20VBK Service Manual

3-11
Input board
Block No. [0][2][0][0]
EP701 QNZ0136-001Z EARTH PLATE
HS701 LV43256-001A HEAT SINK
HS702 LV43256-001A HEAT SINK
RY751 QSK0112-001 RELAY
RY901 QSK0109-001 RELAY
RY902 QSK0109-001 RELAY
RY903 QSK0109-001 RELAY
RY904 QSK0109-001 RELAY
RY905 QSK0109-001 RELAY
RY906 QSK0149-001 RELAY
ST901 QNB0110-001 SPK TERMINAL
ST902 QNB0109-001 SPK TERMINAL
ST903 QNB0108-001 SPK TERMINAL
TH701 QAD0010-351 THERMISTOR 350 Ω
TH702 QAD0010-351 THERMISTOR 350 Ω
TH703 QAD0010-351 THERMISTOR 350 Ω
TH704 QAD0010-351 THERMISTOR 350 Ω
TH705 QAD0010-351 THERMISTOR 350 Ω
TH706 QAD0010-351 THERMISTOR 350 Ω
TH751 QAD0010-351 THERMISTOR 350 Ω
TH752 QAD0010-351 THERMISTOR 350 Ω
TH753 QAD0010-351 THERMISTOR 350 Ω
TH754 QAD0010-351 THERMISTOR 350 Ω
TH755 QAD0010-351 THERMISTOR 350 Ω
TH756 QAD0010-351 THERMISTOR 350 Ω
TH771 QAD0010-351 THERMISTOR 350 Ω
TH772 QAD0010-351 THERMISTOR 350 Ω
TH773 QAD0010-351 THERMISTOR 350 Ω
TH774 QAD0010-351 THERMISTOR 350 Ω
TH775 QAD0010-351 THERMISTOR 350 Ω
TH776 QAD0010-351 THERMISTOR 350 Ω
TH801 QAD0010-351 THERMISTOR 350 Ω
TH802 QAD0010-351 THERMISTOR 350 Ω
TH803 QAD0010-351 THERMISTOR 350 Ω
TW701 QUB050-40FMQP LUG W RE
TW702 QUB111-32PPPP SIN TWIST W RE
WR701 WJK0159-001A E-SI C WIRE C-B
WR702 QJK016-033603 SIN CR C-B WIRE
WR703 QJK016-053800 SIN CR C-B WIRE
WR711 WJK0139-001A E-SI C WIRE C-B
WR712 WJK0139-001A E-SI C WIRE C-B
WR713 WJK0139-002A E-SI C WIRE C-B
WR714 WJK0139-003A E-SI C WIRE C-B
WR715 WJK0139-002A E-SI C WIRE C-B
WR716 WJK0140-001A E-SI C WIRE C-B
WR717 WJK0140-002A E-SI C WIRE C-B
WR731 WJK0149-001A E-SI C WIRE C-B
WR736 WJK0150-001A E-SI C WIRE C-B
 Symbol No. Part No. Part Name Description Local
IC201 NJM4580E-W IC Ope amp.
IC202 TC9164AF-X IC
IC203 TC9164AF-X IC
IC204 NJM5532M-D-XE IC
IC211 TC9162AF-X IC Analog switch
IC212 TC9162AF-X IC Analog switch
IC213 TC9162AF-X IC Analog switch
IC221 TC9459F-X IC
IC222 TC9459F-X IC
IC223 TC9459F-X IC
IC224 TC9459F-X IC
IC241 NJM4580E-W IC Ope amp.
IC251 NJM5532M-D-XE IC
IC252 NJM5532M-D-XE IC
IC253 NJM5532M-D-XE IC
IC254 NJM5532M-D-XE IC
IC261 NJM4580E-W IC Ope amp.
IC262 TC9459F-X IC
IC263 NJM4580E-W IC Ope amp.
IC271 NJM5532M-D-XE IC
 Symbol No. Part No. Part Name Description Local
IC272 NJM4580E-W IC Ope amp.
IC281 NJM4580E-W IC Ope amp.
IC282 NJM2903M-XE IC
IC283 NJM78L05A-T IC
IC321 TC9163AF-X IC
IC322 TC9163AF-X IC
IC381 BA15218N IC Dual Ope. Amp.
IC382 BA15218N IC Dual Ope. Amp.
IC401 NJM2286V-W IC
IC402 MM1118XF-X IC
IC403 MM1118XF-X IC
IC404 NJM2286V-W IC
IC405 LC74761M-9847-X IC
IC441 NJM2286V-W IC
IC461 NJM2286V-W IC
IC462 MM1118XF-X IC
IC463 MM1118XF-X IC
IC464 NJM2285V-W IC
IC465 NJM2283V-W IC
IC466 MM1118XF-X IC
IC467 MM1118XF-X IC
IC468 NJM2283V-W IC
IC471 BU4051BC IC
Analog
multiprexers/DE
multiprexers
IC483 NJM2509V-W IC
IC491 NJM2286V-W IC
IC492 NJM2283V-W IC
Q201 2SK170/L/-T FET
Q202 2SK170/L/-T FET
Q203 2SK170/L/-T FET
Q204 2SK170/L/-T FET
Q205 2SA970/GL/-T TRANSISTOR
Q206 2SA970/GL/-T TRANSISTOR
Q207 KRC105M-T DIGI TRANSISTOR
Q209 2SK2980-X MOS FET
Q210 2SK2980-X MOS FET
Q211 DTC123JKA-X CHIP D.TRANSISTOR
Q212 KRA107S-X TRANSISTOR
Q213 2SC1740S/RS/-T TRANSISTOR
Q214 2SA933S/RS/-T TRANSISTOR
Q271 2SD468/BC/-T TRANSISTOR
Q272 2SD468/BC/-T TRANSISTOR
Q291 2SC3576-JVC-T TRANSISTOR
Q292 2SC3576-JVC-T TRANSISTOR
Q293 2SC3576-JVC-T TRANSISTOR
Q294 2SD2144S/VW/-T TRANSISTOR
Q295 2SC3576-JVC-T TRANSISTOR
Q296 2SC3576-JVC-T TRANSISTOR
Q297 2SC3576-JVC-T TRANSISTOR
Q298 2SC3576-JVC-T TRANSISTOR
Q299 KRA107S-X TRANSISTOR
Q300 DTA143EKA-X TRANSISTOR
Q323 2SC3576-JVC-T TRANSISTOR
Q324 2SC3576-JVC-T TRANSISTOR
Q329 2SC3576-JVC-T TRANSISTOR
Q330 2SC3576-JVC-T TRANSISTOR
Q332 DTC114YKA-X DIGI TRANSISTOR
Q334 DTC114YKA-X DIGI TRANSISTOR
Q342 KRA107S-X TRANSISTOR
Q343 KRA107S-X TRANSISTOR
Q345 KRA107S-X TRANSISTOR
Q351 KRC105M-T DIGI TRANSISTOR
Q401 KTA1267/YG/-T TRANSISTOR
Q402 KTC3199/GL/-T TRANSISTOR
Q403 KTA1267/YG/-T TRANSISTOR
Q404 KTC3199/GL/-T TRANSISTOR
Q405 KTA1267/YG/-T TRANSISTOR
Q407 KTA1267/YG/-T TRANSISTOR
Q409 KRC110M-T TRANSISTOR
Q410 KRC110M-T TRANSISTOR
Q411 KRC107M-T DIGI TRANSISTOR
Q412 KRC107M-T DIGI TRANSISTOR
Q413 DTC114YKA-X DIGI TRANSISTOR
Q2011 2SC3576-JVC-T TRANSISTOR
Q2012 2SC3576-JVC-T TRANSISTOR
Q2013 KRA107S-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
