JVC RX-DP20VBK Service Manual

3-17
AC supply board
Block No. [0][3][0][0]
R4846 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R4901 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R4902 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R4903 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R4904 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R4951 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R4952 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
L321 QQL231K-121Y COIL 120uH K
L322 QQL231K-121Y COIL 120uH K
L402 QQL231K-5R6Y COIL 5.6uH K
L489 NQL012K-2R2X COIL 2.2uH K
L4601 NQL012K-560X COIL 56uH K
CN201 QGA2001F1-14 CONNECTOR W-B (1-14)
CN202 QGA2001F1-09 CONNECTOR W-B (1-9)
CN203 QGA2001F1-12 CONNECTOR W-B (1-12)
CN204 QGA2001F1-03 CONNECTOR W-B (1-3)
CN205 QGB1214K1-10S CONNECTOR B-B (1-10)
CN206 QGB2510K1-06 CONNECTOR B-B (1-6)
CN207 QGA2501F1-03 CONNECTOR W-B (1-3)
CN208 QGA2001F1-08 CONNECTOR W-B (1-8)
CN218 QGA2001F1-03 CONNECTOR W-B (1-3)
CN221 QGB2510K1-10 CONNECTOR B-B (1-10)
CN223 QGA2001F1-08 CONNECTOR W-B (1-8)
CN224 QGA2001F1-07 CONNECTOR W-B (1-7)
CN234 QGA2001F1-09 CONNECTOR W-B (1-9)
CN321 QGB1214K1-10S CONNECTOR B-B (1-10)
CN323 QGF1205F1-15 CONNECTOR FFC/FPC (1-15)
CN324 QGA2001F1-09 CONNECTOR W-B (1-9)
CN325 QGB2510K2-06 CONNECTOR B-B (1-6)
CN401 QGB1214K1-16S CONNECTOR B-B (1-16)
CN402 QGB1224K1-13 CONNECTOR B-B (1-13)
CN451 QGB1214K1-20S CONNECTOR B-B (1-20)
CN452 QGB1224K1-15 CONNECTOR B-B (1-15)
FL301 QQR0590-001 F LTER
FL302 QQR0590-001 F LTER
J201 QNN0502-001 PIN JACK
J203 QNN0502-001 PIN JACK
J204 QNN0503-001 PIN JACK
J321 QNN0502-001 PIN JACK
J322 QNN0506-001 4P N JACK ASSY
J323 QNN0503-001 PIN JACK
J324 QNN0507-001 PIN JACK
J401 QNN0504-001 PIN JACK
J402 QNN0505-001 PIN JACK
J403 QNN0505-001 PIN JACK
J451 QND0090-001 S JACK
J452 QND0029-001 DIN CONNECTOR
J453 QND0029-001 DIN CONNECTOR
J454 QND0089-001 S JACK
J491 QND0027-001 DIN CONNECTOR
J492 QNN0515-001 PIN JACK
J4001 QNN0508-001 PIN JACK
J4002 QNN0509-001 PIN JACK
RY271 QSK0151-001 RELAY
RY272 QSK0151-001 RELAY
RY273 QSK0151-001 RELAY
RY274 QSK0151-001 RELAY
RY275 QSK0151-001 RELAY
RY276 QSK0151-001 RELAY
RY277 QSK0151-001 RELAY
RY278 QSK0151-001 RELAY
RY351 QSK0151-001 RELAY
SW201 QSW0511-001 PUSH SWITCH
WR204 QJK016-091804 SIN CR C-B WIRE
WR307 QJP001-031001 SHI CR C-B WIRE
WR318 QJK016-031403 SIN CR C-B WIRE
WR322 WJP0032-002A E-SH C WIRE C-B
WR323 QJK016-081403 SIN CR C-B WIRE
WR324 WJK0130-001A E-SI C WIRE C-B
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
PW21 QUB056-32QPQP SIN TWIST WIRE
PW22 QUB051-32QPQP SIN TWIST WIRE
PW23 WJK0132-002A E-SI C WIRE C-B
PW25 QUB052-10QPA8 SIN TWIST WIRE
PW26 QUB050-10QPA8 SIN TWIST WIRE
IC44 KIA7806API IC Regulator
 IC61 KIA7812API IC Regulator
Q1 2SC1740S/RS/-T TRANSISTOR
Q2 2SC1740S/RS/-T TRANSISTOR
 Q3 2SD2394/EF/ TRANSISTOR
 Q4 2SD2394/EF/ TRANSISTOR
Q5 2SC1740S/RS/-T TRANSISTOR
Q6 KRA104M-T DIGI TRANSISTOR
Q7 KRC104M-T DIGI TRANSISTOR
Q21 KRC105M-T DIGI TRANSISTOR
Q22 2SD468/BC/-T TRANSISTOR
Q23 2SD468/BC/-T TRANSISTOR
 Q41 2SB1357/EF/-T TRANSISTOR
Q42 KRC102M-T DIGI TRANSISTOR
Q43 KRA104M-T DIGI TRANSISTOR
Q44 KTC3200/GL/-T TRANSISTOR
Q45 2SD2394/EF/ TRANSISTOR
Q46 KRA104M-T DIGI TRANSISTOR
Q47 KRC104M-T DIGI TRANSISTOR
Q53 2SC1740S/RS/-T TRANSISTOR
Q54 KRA104M-T DIGI TRANSISTOR
Q55 KRC104M-T DIGI TRANSISTOR
 Q61 2SD2394/EF/ TRANSISTOR
 Q62 KTA1046/Y/ TRANSISTOR
Q63 2SC1740S/RS/-T TRANSISTOR
Q64 KRC104M-T DIGI TRANSISTOR
Q65 KRC104M-T DIGI TRANSISTOR
D1 MTZJ4.7B-T2 Z DIODE
D2 1SS133-T2 DIODE
D3 1SS133-T2 DIODE
D4 MTZJ6 8B-T2 Z DIODE
 D21 11ES2-T4 DIODE
 D22 11ES2-T4 DIODE
 D23 11ES2-T4 DIODE
 D24 11ES2-T4 DIODE
D25 1SS133-T2 DIODE
D26 MTZJ6 2A-T2 Z DIODE
D27 MTZJ6 2A-T2 Z DIODE
 D41 RS403L DIODE
D45 MTZJ5.6C-T2 Z DIODE
 D48 11ES2-T4 DIODE
D49 MTZJ36C-T2 Z DIODE
D50 MTZJ8 2C-T2 Z DIODE
D51 HZ6B1L-T2 Z DIODE
 D61 31DF2-FC6 FR DIODE
 D62 31DF2-FC6 FR DIODE
 D63 31DF2-FC6 FR DIODE
 D64 31DF2-FC6 FR DIODE
D65 1SS133-T2 DIODE
D66 1SS133-T2 DIODE
D67 1SS133-T2 DIODE
D68 1SS133-T2 DIODE
D69 HZ18-2L-T2 Z DIODE
D70 HZ18-2L-T2 Z DIODE
D71 1SS133-T2 DIODE
D72 1SS133-T2 DIODE
D73 1SS133-T2 DIODE
D74 1SS133-T2 DIODE
D75 1SS133-T2 DIODE
D101 1SS133-T2 DIODE
 D4001 31DF2-FC6 FR DIODE
 D4002 31DF2-FC6 FR DIODE
 D4003 31DF2-FC6 FR DIODE
 D4004 31DF2-FC6 FR DIODE
C1 QETN1CM-107Z E CAPACITOR 100uF 16V M
