3-19
Front board
Block No. [0][4][0][0]
K1 QQR0779-001Z COIL
K2 QQR0779-001Z COIL
RY1 QSK0109-001 RELAY
RY21 QSK0098-001 RELAY
RY101 QSK0131-001 RELAY
RY102 QSK0131-001 RELAY
RY103 QSK0131-001 RELAY
RY104 QSK0131-001 RELAY
TH41 QAD0095-4R7Z P THERMISTOR 4.7
Ω
M
TW41 QUB220-08HPDM SIN TWIST W RE
TW42 QUB220-08HPDM SIN TWIST W RE
TW51 QUB220-10HPDM LUG W RE
TW81 QUB270-07HPDM SIN TWIST W RE
WR12 QJK016-056500 SIN CR C-B WIRE
WR13 QJK016-096004 SIN CR C-B WIRE
WR14 QJK016-090802 SIN CR C-B WIRE
WR26 QJK016-081103 SIN CR C-B WIRE
WR41 WJK0153-001A E-SI C WIRE C-B
WR42 QJK016-031503 E-SI C WIRE C-B
WR48 QJK016-041204 E-SI C WIRE C-B
WR81 QJK015-041204 E-SI C WIRE C-B
WR85 QJP001-033801 SHI CR C-B WIRE
WR86 QJK016-022202 SIN CR C-B WIRE
WR101 QJK012-063801 E-SI C WIRE C-B
WR102 QJK017-025202 E-SI C WIRE C-B
Symbol No.
Part No. Part Name Description Local
IC301 NJM2406F-X IC
IC961 MN101CP49K923 IC
IC962 MN101C35DHN IC
IC963 IC-PST9139-T IC
IC964 GP1UM271XK IR DETECT UNIT
IR detecting unit for
remote control
IC965 BU2092F-X IC
IC967 TA8409S IC Motor driver
Q1003 KRC107M-T DIGI TRANSISTOR
Q1011 KRC107M-T DIGI TRANSISTOR
Q1012 KRA107M-T DIGI TRANSISTOR
Q1013 KRA107M-T DIGI TRANSISTOR
Q1014 KRA107M-T DIGI TRANSISTOR
Q1015 KRA107M-T DIGI TRANSISTOR
Q1016 KRA107M-T DIGI TRANSISTOR
Q1017 KRA107M-T DIGI TRANSISTOR
Q1018 KRA107M-T DIGI TRANSISTOR
Q1019 KRA107M-T DIGI TRANSISTOR
Q1020 KRA107M-T DIGI TRANSISTOR
Q1021 KRC111M-T TRANSISTOR
Q1022 KRC109M-T DIGI TRANSISTOR
Q1023 KRC107M-T DIGI TRANSISTOR
Q1031 KRA107M-T DIGI TRANSISTOR
Q1032 KRA107M-T DIGI TRANSISTOR
Q1033 KRA107M-T DIGI TRANSISTOR
Q1034 KRA107M-T DIGI TRANSISTOR
Q1035 KRC103M-T TRANSISTOR
Q1201 KRA107M-T DIGI TRANSISTOR
Q1202 KTA1273/Y/-T TRANSISTOR
D1001 11ES2-T4 DIODE
D1002 11ES2-T4 DIODE
D1003 11ES2-T4 DIODE
D1004 11ES2-T4 DIODE
D1005 1SS133-T2 DIODE
D1023 1SS133-T2 DIODE
D1024 1SS133-T2 DIODE
D1031 SLR-342VC-T LED
D1032 SLA-370LT3F LED
D1033 SLA-370LT3F LED
D1034 SLA-370LT3F LED
D1201 1SS133-T2 DIODE
Symbol No.
Part No. Part Name Description Local
D1202 1SS133-T2 DIODE
D1203 MTZJ12C-T2 Z DIODE
D1211 MTZJ6 2C-T2 Z DIODE
C28 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C471 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
C472 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
C473 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
C475 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C476 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C478 QDVB1EZ-223Y C CAPACITOR 0 022uF 25V Z
C479 QFN31HJ-473Z M CAPACITOR 0 047uF 50V J
C1001 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1002 QCZ0202-155Z C CAPACITOR 1 5uF 25V Z
C1003 QEZ0361-479 E.D.L. CAPACITOR 0 047F
C1004 QEKC1HM-225Z E CAPACITOR 2 2uF 50V M
C1005 NCF21HZ-223X C CAPACITOR 0 022uF 50V Z
C1006 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1007 QCZ0202-155Z C CAPACITOR 1 5uF 25V Z
C1008 NCF21HZ-223X C CAPACITOR 0 022uF 50V Z
C1009 NCB31HK-103X C CAPACITOR 0 01uF 50V K
C1011 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1012 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1013 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1021 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C1025 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1034 QDVB1EZ-223Y C CAPACITOR 0 022uF 25V Z
C1035 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C1036 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C1037 QCZ0202-155Z C CAPACITOR 1 5uF 25V Z
C1038 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C1041 NCB31HK-471X C CAPACITOR 470pF 50V K
C1042 NCB31HK-471X C CAPACITOR 470pF 50V K
C1043 NCB31HK-471X C CAPACITOR 470pF 50V K
C1044 NCB31HK-471X C CAPACITOR 470pF 50V K
C1045 NCB31HK-471X C CAPACITOR 470pF 50V K
C1046 NCB31HK-471X C CAPACITOR 470pF 50V K
C1047 NCB31HK-471X C CAPACITOR 470pF 50V K
C1059 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1060 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1061 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C1201 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1202 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1203 QER61AM-107Z E CAPACITOR 100uF 10V M
C1204 QER61AM-107Z E CAPACITOR 100uF 10V M
C1205 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1211 NCB31HK-221X C CAPACITOR 220pF 50V K
C1212 NCB31HK-221X C CAPACITOR 220pF 50V K
C1213 NCB31HK-221X C CAPACITOR 220pF 50V K
C3734 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
R471 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R472 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R473 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R1003 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R1004 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1005 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R1006 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1011 QRE141J-513Y C RESISTOR 51k
Ω
1/4W J
R1021 QRE141J-471Y C RESISTOR 470
Ω
1/4W J
R1022 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1023 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1024 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R1025 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1030 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1031 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R1032 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R1033 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R1034 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R1035 QRE141J-100Y C RESISTOR 10
Ω
1/4W J
R1036 QRE141J-100Y C RESISTOR 10
Ω
1/4W J
R1037 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R1038 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R1039 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R1041 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1042 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1043 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1044 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
