1-2 (No.82996)
SPECIFICATION
Specifications shown are for SP mode unless otherwise specified.
E.& O.E. Design and specifications subject to change without notice. Don't service the product yourself.
GENERAL
Power requirement AC 120V, 60 Hz
Power consumption Power on : 19 W, Power off : 1.6 W
Temperature Operating : 5°C to 40°C (41°F to 104°F), Storage : -20°C to 60°C(-4°F to140°F)
Operating position Horizontal only
Dimensions (WxHxD) 435 mm × 94 mm × 242 mm (17-3/16" × 3-3/4" × 9-3/4")
Weight 2.8 kg (6.2 lbs)
Format S-VHS/VHS NTSC standard
Maximum recording time (SP) : 210 min. with ST-210 video cassette, (EP) : 630 min. with ST-210 video cassette
VIDEO/AUDIO
Signal system NTSC-type color signal and EIA monochrome signal, 525 lines/60 fields
Recording/Playback system DA4 (Double Azimuth) head helical scan system
Signal-to-noise ratio 45 dB
Horizontal resolution 230 lines(VHS) / 400 lines(S-VHS)
Frequency range Normal audio : 70 Hz to 10,000 Hz, Hi-Fi audio : 20 Hz to 20,000 Hz
Input/Output RCA connectors (IN × 2, OUT × 1), S-video connectors (IN × 2, OUT × 1)
TUNER
Tuning system Frequency synthesized tuner
Channel coverage VHF : Channels 2-13, UHF : Channels 14-69, CATV : 113 Channels
RF output Channel 3 or 4 (switchable; preset to Channel 3 when shipped) 75 ohms, unbalanced
TIMER
Clock reference Quartz
Program capacity 1-year programmable timer/8 programs
Memory backup time Approx. 27 months
Estimated figure base on supplied fresh battery; actual performance may differ.
ACCESSORIES
Provided accessories Infrared remote control unit, "AA" battery × 2, S-video cable (4-pin),
RF cable (F-type) Audio/Video cable, BNC/RCA adapter × 2
