JVC SR-V101US Service Manual

3-10(No.82996)
A/C HEAD BOARD ASSEMBLY <12>
ADV.JOG BOARD ASSEMBLY <38>
LOADING MOTOR BOARD ASSEMBLY <55>
C.BOX/R.P BOARD ASSEMBLY <99>
C1415 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1416 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C1417 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1421 NDC21HJ-330X C CAPACITOR 33pF 50V J
C1422 NDC21HJ-680X C CAPACITOR 68pF 50V J
C1423 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1424 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1425 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1426 NDC21HJ-390X C CAPACITOR 39pF 50V J
C1428 NDC21HJ-220X C CAPACITOR 22pF 50V J
C1429 QEKJ0JM-337Z E CAPACITOR 330uF 6.3V M
C1430 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1432 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1433 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1435 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1436 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1437 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1438 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1439 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1440 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1441 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1442 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1444 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1445 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1446 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C1447 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1448 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C1449 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1450 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1451 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C1452 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1453 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1454 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1455 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1463 QEKJ0JM-336Z E CAPACITOR 33uF 6.3V M
C1468 NDC21HJ-101X C CAPACITOR 100pF 50V J
C1471 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1472 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
C1473 NCF21EZ-104X C CAPACITOR 0.1uF 25V Z
R1401 NRSA02J-121X MG RESISTOR 120 Ω 1/10W J
R1402 NRSA02J-101X MG RESISTOR 100 Ω 1/10W J
R1404 NRSA02J-272X MG RESISTOR 2.7k Ω 1/10W J
R1406 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R1410 NRSA02J-271X MG RESISTOR 270 Ω 1/10W J
R1411 NRSA02J-152X MG RESISTOR 1.5k Ω 1/10W J
R1413 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R1415 NRVA02D-221X CMF RESISTOR 220 Ω 1/10W D
R1416 NRSA02J-104X MG RESISTOR 100k Ω 1/10W J
R1417 NRSA02J-101X MG RESISTOR 100
Ω 1/10W J
R1418 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R1421 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R1426 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R1427 NRSA02J-333X MG RESISTOR 33k Ω 1/10W J
R1428 NRSA02J-393X MG RESISTOR 39k
Ω 1/10W J
R1429 NRSA02J-182X MG RESISTOR 1.8k
Ω 1/10W J
R1430 NRSA02J-222X MG RESISTOR 2.2k Ω 1/10W J
R1431 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R1433 NRSA02J-510X MG RESISTOR 51 Ω 1/10W J
R1434 NRVA02D-153X CMF RESISTOR 15k
Ω 1/10W D
R1435 NRVA02D-473X CMF RESISTOR 47k
Ω 1/10W D
R1436 NRVA02D-393X CMF RESISTOR 39k Ω 1/10W D
R1437 NRSA02J-392X MG RESISTOR 3.9k
Ω 1/10W J
R1438 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R1439 NRSA02J-273X MG RESISTOR 27k Ω 1/10W J
R1440 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R1445 NRVA02D-393X CMF RESISTOR 39k
Ω 1/10W D
R1446 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R1447 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R1448 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
R1449 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R1450 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R1452 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R1453 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R1455 NRSA02J-681X MG RESISTOR 680
Ω 1/10W J
R1459 NRSA02J-681X MG RESISTOR 680 Ω 1/10W J
R1460 NRSA02J-273X MG RESISTOR 27k
Ω 1/10W J
 Symbol No. Part No. Part Name Description Local
L1402 QQL071J-6R8Y COIL 1.20 Ω 6.8uH J
L1403 QQL071J-6R8Y COIL 1.20 Ω 6.8uH J
L1404 QQL071J-6R8Y COIL 1.20 Ω 6.8uH J
L1405 QQL29BJ-100Z P COIL 0.40 Ω 10uH J
L1406 QQL071J-330Y COIL 3.80 Ω 33uH J
L1407 QQL29BJ-100Z P COIL 0.40
Ω 10uH J
B1401 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
B1412 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
CN1401 QGG2502K1-17 CONNECTOR (1-17)
LC1401 QQL29BJ-101Z P COIL 3.00 Ω 100uH J
LC1402 QQR0521-006Z NOISE FILTER
SD1 LP30706-001D SHIELD FRAME(S-VHS)
W1401 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
W1402 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
 Symbol No. Part No. Part Name Description Local
PW1 LPA10158-01A1 A/C HEAD BOARD ASSY
 Symbol No. Part No. Part Name Description Local
PW1 LPA10225-01C3 ADV.JOG BOARD ASSY
R7047 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7048 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
CN7003 QGF1209F1-04 CONNECTOR FFC/FPC (1-4)
S7030 QSW0456-002Z TACT SWITCH REC LINK
S7031 QSW0456-002Z TACT SWITCH 24HR.QUICK PROGRAM
UN7001 QSW0905-001 ROTARY ENCODER
 Symbol No. Part No. Part Name Description Local
PW1 LPA10158-01A2 LOADING MOTOR BOARD ASSY
 Symbol No. Part No. Part Name Description Local
PW1 LPA10225-01C2 C.BOX/R.P BOARD ASSY
R7155 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7156 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
J7104 QNS0214-001 3.5 JACK REMOTE IN
J7105 QNS0214-001 3.5 JACK REMOTE OUT
 Symbol No. Part No. Part Name Description Local
