JVC SR-V101US Service Manual

3-4(No.82996)
2. PARTS LIST
PACKING AND ACCESSORY ASSEMBLY <M1>
FINAL ASSEMBLY <M2>
MECHANISM ASSEMBLY <M4>
 Symbol No. Part No. Part Name Description Local
301 LP31089-067B PACKING CASE
302 LP31091-001C CUSHION ASSY
303 LP41038-001A POLY BAG
304 LP40967-009A MINI CUSHION
306 LP20303-018B REMOCON
306A LP40225-002A COVER(BATTERY)
307 ------------ BATTERY R6 TYPE(x2)
308 QPC02202230P POLY BAG 22cm x 22cm
 310 LPT0887-001A INST.BOOK (ENGLISH)
311 QPC02503530P POLY BAG 25cm x 35cm
312 QAM0523-001 RF CABLE
313 QAM0522-001 A/V CABLE
314 QAM0516-002 S CABLE
315 QAM0259-001 ADAPTOR PLUG (x2)
316 BT-51010-2 WARRANTY CARD
319 BT-51024-1 SER.NET CARD
 Symbol No. Part No. Part Name Description Local
 501 LP10464-012A FRONT PANEL ASSY
501A LP21080-013A CASSETTE DOOR
501B PQ46448 TORSION SPRING
501C LP31161-001A WINDOW
501D LP10448-012A COVER
 502 LP10418-005A TOP COVER
503 QYSDSF3010RA TAP SCREW M3 x 10mm TOP(x3)
505 PDV2545B DRUM FINAL ASSY
510 QYSPSPD3008ZA SCREW M3 x 8mm DRUM(x3)
 511 LP10417-009A BOTTOM CHASSIS
515 QYSDSF4012ZA TAP SCREW M4 x 12mm MECHANISM(x2)
516 QYSPSF3010ZA TAP SCREW M3 x 10mm MECHANISM(x2)
529 LP31095-004A KNOB ASSY
530 QYSDSF2608ZA TAP SCREW M2.6 x 8mm ADV.JOG(x3)
 550 LP41041-001A INSULATOR
551 QYSDSF3008ZA TAP SCREW M3 x 8mm POWER CORD
WR1 QUQ212-0414CG FFC WIRE ADV.JOG CN7003-MAIN CN7001
 Symbol No. Part No. Part Name Description Local
1 LP21039-001Y MAIN DECK ASSY
3 LP40097-002E GUIDE POLE CAP
4 NAH0004-001 FE HEAD
15 LP30958-001B LOADING GEAR BASE
16 QYTPST2620ZA TAP SCREW M2.6 x 20mm(x2)
18 LP40798-001A
LOADING GEAR(SUPPLY) ASSY
18A LP21040-001A LOADING GEAR(SUPPLY)
18B LP40799-001A LOADING ARM(SUPPLY) ASSY
19 LP40837-001A TORSION SPRING(SUPPLY)
20 LP40903-002B FIXING PLATE
21 LP40806-001D POLE BASE ASSY(SUPPLY)
22 LP30959-001B LOADING GEAR
23 LP40802-001C
LOADING GEAR(TAKE UP) ASSY
23A LP21041-001D LOADING GEAR(TAKE UP)
23B LP40803-001A
LOADING ARM(TAKE UP) ASSY
24 LP40838-001A TORSION SPRING(TAKE UP)
26 LP40808-001E POLE BASE ASSY(TAKE UP)
36 LP21055-001G TAKE UP LEVER
37 LP40943-001A TENSION SPRING
38 LP40859-001D TAKE UP HEAD
39 LP30961-001C LID GUIDE
42 LP40810-001C PINCH ROLLER ARM ASSY
44 LP40840-001D TORSION SPRING
46 LP30963-001C PRESS LEVER
47 PQM30017-24 SLIT WASHER
48 LP40930-002F S-SWITCH
49 LP40813-001D GUIDE ARM ASSY
50 LP40841-001A TORSION SPRING
52 NAH0003-001 AC HEAD
53 LP30965-001A HEAD BASE
55 LP40842-001D COMP.SPRING
56 QYTDST2006MA TAP SCREW M2 x 6mm
57 LP41036-002A A/C ADJ.SCREW (x2)
58 QYTDST2606ZA TAP SCREW M2.6 x 6mm(x2)
59 QAR0289-001 LOADING MOTOR
60 QYTPSP3003ZA SCREW M3 x 3mm(x2)
61 LP21056-002J MOTOR BRACKET
62 QYTPST2620ZA TAP SCREW M2.6 x 20mm
63 LP40814-001B WORM BEARING
64 LP21044-001E CONTROL CAM
65 PQM30017-24 SLIT WASHER
66 LP40815-001A WORM GEAR
67 LP40816-001B HELICAL GEAR
68 LP40817-001A CONNECT GEAR
69 LP10400-001N CONTROL PLATE
70 LP40843-001A TORSION SPRING
71 LP40818-001B TENSION ARM ASSY
72 LP40844-001F TENSION SPRING
73 LP21045-001E TENSION ARM BASE
74 LP40821-001A TENSION BAND ASSY
75 LP30967-001B BAND HOLDER-1
76 LP30968-001C BAND HOLDER-2
77 LP40822-002B ADJUST PIN
78 LP31000-005E TENSION ARM LEVER
79 LP21046-001C MAIN BRAKE(TAKE UP)
80 LP40824-001A BAND BRAKE ASSY
81 LP30969-002B BRAKE LEVER
82 LP30003-033B TENSION SPRING
83 LP30003-035B TENSION SPRING
84 LP40825-001B CAPSTAN BRAKE ASSY
 85 QAR0267-002 CAPSTAN MOTOR
86 QYTPSG2606ZA TAP SCREW M2.6 x 6mm(x3)
87 LP30005-010A BELT CAPSTAN MOTOR
88 LP30970-001A IDLER ARM
89 LP40828-004A IDLER GEAR 1 (x2)
90 LP40829-002A IDLER GEAR 2 (x2)
93 LP40934-001B CLUTCH UNIT
94 PQM30017-47 SLIT WASHER
95 LP30973-001A DIRECT GEAR
96 LP40939-001A COMP.SPRING
102 LP30974-001C CHANGE LEVER
105 LP21049-001A REEL DISK (x2)
107 LP30017-004A SPACER REEL DISK(x2)
110 LP10401-001L SIDE FRAME(L)
111 LP10402-001M SIDE FRAME(R)
112 QYTDST2606ZA TAP SCREW M2.6 x 6mm(x2)
113 LP40917-001D TORSION SPRING
114 LP30976-001F SIDE PLATE
115 LP30977-002D LIMIT PLATE
116 LP40846-001C LIMIT SPRING
117 LP31100-002A DRIVE LEVER
118 LP30978-001B DRIVE ARM(L)
119 LP30979-001S DRIVE ARM(R)
120 LP40847-001B TORSION SPRING
121 LP30980-001F CONNECT PLATE
122 LP10403-001C SIDE HOLDER(L)
123 LP10404-001E SIDE HOLDER(R)
124 LP30983-001B LOCK LEVER(L)
125 LP30984-001B LOCK LEVER(R)
126 LP40924-001D TENSION SPRING (x2)
127 LP40972-001A EARTH SPRING(1)
128 LP40857-001B EARTH SPRING(2)
130 LP30981-001G CASETTE HOLDER ASSY
134 LP21051-002C REC SAFETY LEVER
137 LP21052-001K TOP FRAME
151 LP30985-002M DOOR OPENER
161 LP40993-001A TAPE GUIDE
171 QYTDST2606ZA TAP SCREW M2.6 x 6mm
172 LP31014-002A WIRE HOLDER
WR1 WJT0117-001A E-CARD WIRE
WR2 WJT0067-001B E-CARD WIRE
A/C HEAD CN2001
WR3 WJS0022-001A E-FL/RB WIRE LOADING MOTOR
 Symbol No. Part No. Part Name Description Local
