JVC SR-V101US Service Manual

(No.82996)3-5
MAIN BOARD ASSEMBLY <03>
 Symbol No. Part No. Part Name Description Local
PW1 LPA10225-01C1 MAIN BOARD ASSY
IC1 JCP8060-NSA IC
IC2 74HC4052D-X IC
IC2 or CD74HC4052M-X IC
IC501 JCP8058 IC
IC501 or JCP8058-2 IC
IC903 MM1117XF-XE IC
 IC2201 AN3663FBP IC
IC3001 MN101D06HNC IC(MCU) MASK
IC3003 IC-PST3425U-X IC
IC3003 or S-80825CNNB-X IC
IC3004 LPN0850-001E-01 IC(EEPROM) *(REFER TO BELOW)
IC7002 GP1UM291QK IR DETECT UNIT 38kHz
Q1 DTC144WKA-X DIGI TRANSISTOR
Q1 or UN221E-X TRANSTSTOR
Q1 or RT1N44HC-X DIGI TRANSISTOR
Q401 2SA1576A/QR/-X TRANSISTOR
Q402 2SA1576A/QR/-X TRANSISTOR
Q403 DTC144WUA-X DIGI TRANSISTOR
Q403 or PDTC144WU-X DIGI TRANSISTOR
Q403 or UN521E-X DIGI TRANSISTOR
Q403 or RN1309-X DIGI TRANSISTOR
Q404 DTC144WUA-X DIGI TRANSISTOR
Q404 or PDTC144WU-X DIGI TRANSISTOR
Q404 or UN521E-X DIGI TRANSISTOR
Q404 or RN1309-X DIGI TRANSISTOR
Q405 2SA1576A/QR/-X TRANSISTOR
Q901 2SA1576A/QR/-X TRANSISTOR
Q901 or 2PA1576/R/-X TRANSISTOR
Q902 2SA1037AK/QR/-X TRANSISTOR
Q902 or 2SA1530A/QR/-X SI TRANSISTOR
Q903 2SA1037AK/QR/-X TRANSISTOR
Q903 or 2SA1530A/QR/-X SI TRANSISTOR
Q2001 2SC2412K/QRS/-X TRANSISTOR
Q2001 or 2SD601A/QRS/-X TRANSISTOR
Q2001 or 2SC3928A/QRS/-X TRANSISTOR
Q2002 2SC2412K/QRS/-X TRANSISTOR
Q2002 or 2SD601A/QRS/-X TRANSISTOR
Q2002 or 2SC3928A/QRS/-X TRANSISTOR
Q2003 DTA144WKA-X TRANSISTOR
Q2003 or UN211E-X DIGI TRANSISTOR
Q2003 or RT1P44HC-X DIGI TRANSISTOR
Q2051 2SD601A/QRS/-X TRANSISTOR
Q2051 or 2SC2412K/QRS/-X TRANSISTOR
Q2051 or 2SC3928A/QRS/-X TRANSISTOR
Q2052 2SA1037AK/QR/-X TRANSISTOR
Q2052 or 2SB709A/QR/-X TRANSISTOR
Q2052 or 2SA1530A/QR/-X SI TRANSISTOR
Q2053 DTC144WKA-X DIGI TRANSISTOR
Q2053 or UN221E-X TRANSTSTOR
Q2053 or RT1N44HC-X DIGI TRANSISTOR
Q2054 2SA1037AK/QR/-X TRANSISTOR
Q2054 or 2SB709A/QR/-X TRANSISTOR
Q2054 or 2SA1530A/QR/-X SI TRANSISTOR
Q2055 DTC144WKA-X DIGI TRANSISTOR
Q2055 or UN221E-X TRANSTSTOR
Q2055 or RT1N44HC-X DIGI TRANSISTOR
Q2061 2SD601A/QRS/-X TRANSISTOR
Q2061 or 2SC2412K/QRS/-X TRANSISTOR
Q2061 or 2SC3928A/QRS/-X TRANSISTOR
Q2062 2SA1037AK/QR/-X TRANSISTOR
Q2062 or 2SB709A/QR/-X TRANSISTOR
Q2062 or 2SA1530A/QR/-X SI TRANSISTOR
Q2063 DTC144WKA-X DIGI TRANSISTOR
Q2063 or UN221E-X TRANSTSTOR
Q2063 or RT1N44HC-X DIGI TRANSISTOR
Q2201 DTA144WUA-X DIGI TRANSISTOR
Q2201 or PDTA144WU-X DIGI TRANSISTOR
Q2201 or UN511E-X DIGI TRANSISTOR
Q2201 or RN2309-X DIGI TRANSISTOR
Q2202 DTC144WUA-X DIGI TRANSISTOR
Q2202 or PDTC144WU-X DIGI TRANSISTOR
Q2202 or UN521E-X DIGI TRANSISTOR
Q2202 or RN1309-X DIGI TRANSISTOR
Q2203 2SC4081/QRS/-X TRANSISTOR
Q2203 or 2PC4081/R/-X TRANSISTOR
Q2203 or 2SD1819A/QRS/-X TRANSISTOR
Q2204 2SC4081/QRS/-X TRANSISTOR
Q2204 or 2PC4081/R/-X TRANSISTOR
Q2204 or 2SD1819A/QRS/-X TRANSISTOR
Q2251 DTC144WKA-X DIGI TRANSISTOR
Q2251 or UN221E-X TRANSTSTOR
Q2251 or RT1N44HC-X DIGI TRANSISTOR
Q2252 DTC144WUA-X DIGI TRANSISTOR
Q2252 or PDTC144WU-X DIGI TRANSISTOR
Q2252 or UN521E-X DIGI TRANSISTOR
Q2252 or RN1309-X DIGI TRANSISTOR
Q2253 DTC144WKA-X DIGI TRANSISTOR
Q2253 or UN221E-X TRANSTSTOR
Q2253 or RT1N44HC-X DIGI TRANSISTOR
Q2254 DTC114EUA-X DIGI TRANSISTOR
Q2254 or PDTC114EU-X DIGI TRANSISTOR
Q2254 or UN5211-X DIGI TRANSISTOR
Q2254 or RN1302-X DIGI TRANSISTOR
Q3002 PTZ-NV16A IC(PHOTO SENSOR
Q3004 2SD601A/QRS/-X TRANSISTOR
Q3004 or 2SC2412K/QRS/-X TRANSISTOR
Q3004 or 2SC3928A/QRS/-X TRANSISTOR
Q4001 UN2211-X TRANSISTOR
Q4001 or DTC114EKA-X TRANSISTOR
Q4001 or RT1N141C-X DIGI TRANSISTOR
Q4002 2SD601A/QRS/-X TRANSISTOR
Q4002 or 2SC2412K/QRS/-X TRANSISTOR
Q4002 or 2SC3928A/QRS/-X TRANSISTOR
 Q5101 2SK2043-CB14 FET
 Q5101 or 2SK2043 FET
Q5102 2SD2144S/UV/-T TRANSISTOR
Q5301 2SC1740S/RS/-T TRANSISTOR
Q5301 or 2SC3199/YG/-T TRANSISTOR
Q5303 2SC5739/QP/ TRANSISTOR
Q5304 2SD2144S/UV/-T TRANSISTOR
Q5305 DTA114EKA-X DIGI TRANSISTOR
Q5305 or UN2111-X TRANSISTOR
Q5305 or RT1P141C-X DIGI TRANSISTOR
Q5306 DTC114EKA-X TRANSISTOR
Q5306 or UN2211-X TRANSISTOR
Q5306 or RT1N141C-X DIGI TRANSISTOR
Q6030 2SB709A/QR/-X TRANSISTOR
Q6030 or 2SA1037AK/QR/-X TRANSISTOR
Q6030 or 2SA1530A/QR/-X SI TRANSISTOR
Q7001 2SB709A/QR/-X TRANSISTOR
Q7001 or 2SA1037AK/QR/-X TRANSISTOR
Q7001 or 2SA1530A/QR/-X SI TRANSISTOR
Q7002 2SB709A/QR/-X TRANSISTOR
Q7002 or 2SA1037AK/QR/-X TRANSISTOR
Q7002 or 2SA1530A/QR/-X SI TRANSISTOR
Q7003 2SB709A/QR/-X TRANSISTOR
Q7003 or 2SA1037AK/QR/-X TRANSISTOR
Q7003 or 2SA1530A/QR/-X SI TRANSISTOR
Q7004 2SB709A/QR/-X TRANSISTOR
Q7004 or 2SA1037AK/QR/-X TRANSISTOR
Q7004 or 2SA1530A/QR/-X SI TRANSISTOR
Q7005 2SB709A/QR/-X TRANSISTOR
Q7005 or 2SA1037AK/QR/-X TRANSISTOR
Q7005 or 2SA1530A/QR/-X SI TRANSISTOR
Q7006 2SB709A/QR/-X TRANSISTOR
Q7006 or 2SA1037AK/QR/-X TRANSISTOR
Q7006 or 2SA1530A/QR/-X SI TRANSISTOR
Q7007 2SB709A/QR/-X TRANSISTOR
Q7007 or 2SA1037AK/QR/-X TRANSISTOR
Q7007 or 2SA1530A/QR/-X SI TRANSISTOR
Q7008 DTC143TKA-X DIGI TRANSISTOR
Q7008 or UN2216-X DIGI TRANSISTOR
Q7009 DTC143TKA-X DIGI TRANSISTOR
Q7009 or UN2216-X DIGI TRANSISTOR
Q7010 DTC143TKA-X DIGI TRANSISTOR
Q7010 or UN2216-X DIGI TRANSISTOR
Q7011 DTC143TKA-X DIGI TRANSISTOR
Q7011 or UN2216-X DIGI TRANSISTOR
Q7012 DTC143TKA-X DIGI TRANSISTOR
Q7012 or UN2216-X DIGI TRANSISTOR
Q7013 DTC143TKA-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
*The VCR goes to jig RCU mode after replacing the EEPROM and the VCR does not accept some RCU command.
Therefore please set the VCR to the user RCU mode after replacing the EEPROM.
The method of setting the VCR to the user RCU mode is written on the service manual.
