2-31
9. 21 Ent. guide base assembly / 22 Worm wheel 2 /
23 Timing belt / 24 Center gear assembly
Fig. 2-13-9
Fig. 2-13-10
<Note 11> : How to attach the worm wheel 2 22 .
10.
25 Reel drive pulley assembly / 26 Push plate
27 Clutch lock gear(2) / 28 Clutch lock gear (1)
Fig. 2-13-9A
Align the phase of the rotary encoder assembly 34 ,
then attach it by aligning the phase hole of the mecha-
nism assembly.
26
(
S2
)
21
22
24
23
<Note11>
27
(
W1
)
(
W3
)
(
P6
)
28
26
(
W1
)
25
34
22
Phase alignment
Mark (Red)
