JVC TH-M337B User Manual

- 9 -
Connect Power
Risk of product damage!
- Ensure that the power supply voltage
corresponds to the voltage printed on the
back or the underside of the unit.
- Before connecting the AC power cord, ensure
you have completed all other connections.
Soundbar
• Connect the mains cable to the AC~ Socket
of main unit and then into a mains socket.
Subwoofer
• Connect the mains cable to the AC~ Socket of
the subwoofer and then into a mains socket.
Pairing the Wireless Subwoofer with the Main Unit
Automatic pairing
The subwoofer and soundbar will automatically pair when both units are plugged into the mains
sockets and turned on. No cable is needed for connecting the two units.
• When the subwoofer is pairing with the main unit, the Pair Indicator will flash fast.
• When the subwoofer is paired with the main unit, the Pair Indicator will light up.
NOTE:
- Do not press the Pair button on the rear of the subwoofer, except for manual pairing.
- If the automatic pairing fails, pair the subwoofer with the main unit manually.
Manual pairing
1. Ensure that all the cables are well connected and the main unit is in Standby mode.
2. Press and hold the Pair button on the rear of the subwoofer for a few seconds. The subwoofer will
enter the pairing mode and the Pair Indicator will blink quickly.
3. Press the button on the main unit or on the remote control to switch the main unit on.
4. After the wireless connection succeeded, the Pair Indicator will light up.
5. If the Pair indicator blinks, the wireless connection has failed. Unplug the cable of the subwoofer and
then reconnect the main cable after 3 minutes. Repeat step 1 ~ 4.
NOTE:
• If the wireless connection fails again, check if there is conict or strong interference
(for example, interference from an electronic device) around your location. Remove these conicts or
strong interferences and repeat the above procedures.
• The subwoofer should be within 6m (18 feet) of the soundbar in an open area.
• If a TV or an external device is connected, the main unit only AUX model and the subwoofer will
switch on automatically when the TV or the external device is switched on.
• If the main unit is not connected with the subwoofer and it is in On mode, the POWER Indicator will
ash. Follow step 1 ~ 4 above to pair the subwoofer to the main unit.

JVC TH-M337B Specifications

Power

sound bar power supply	AC120V~ 60Hz
sound bar power consumption	30 W
subwoofer power requirements	AC120V~ 60Hz
subwoofer power consumption	30 W

Audio

sound bar output power	30 W x 2
sound bar audio input sensitivity	700 mV
sound bar frequency response	120Hz - 20KHz
subwoofer output power	60 W
subwoofer frequency response	40 Hz - 120 Hz

Electrical Characteristics

sound bar speaker impedance	8 Ω x 2
subwoofer impedance	4 Ω

Bluetooth

bluetooth version	V 4.2
bluetooth maximum power transmitted	<20 dbm
bluetooth frequency bands	2402 MHz ~ 2480 MHz

Wireless Subwoofer

2.4g hz wireless subwoofer maximum power transmitted	<10 dbm
2.4g hz wireless subwoofer frequency bands	2400 MHz ~ 2483 MHz

Remote Control

remote control distance	6 m
remote control angle	30°
remote control battery type	CR2025

Dimensions and Weight

sound bar unit dimension	952 x 63 x 65.7 mm
subwoofer dimension	465 x 255 x 95 mm
