22
7 DSP
STADIUM
STADIUM mode adds clarity and spreads the sound, like in
an outdoor stadium.
All Channel Stereo
All Channel Stereo (ALL ST) mode can reproduce a larger
stereo sound field using all the connected (and activated)
speakers.
All Channel Stereo can be used while reproducing 2
channel stereo source.
7 Indicators on the display window
Digital signal format indicators
LPCM: Lights when Linear PCM signal comes in.
GD: Lights when Dolby Digital signals come in.
C: Lights when DTS Digital (Surround) signals come in.
No indication: No digital signal indicator lights when
analog signals come in.
Dolby Surround mode indicator
GPLII: Lights when Dolby Pro Logic II mode is activated.
Surround indicator
SURR: Lights when the surround mode is activated.
Source signal indicators, etc.
Light to indicate the incoming signals.
a: Lights when the front left channel
signal comes in.
b: Lights when the center channel signal comes in.
c: Lights when the front right channel signal comes in.
d: Lights when the LFE channel signal comes in.
g: Lights when the surround left channel signal comes in.
i: Lights when the surround right channel signal comes
in.
h: Lights when the monaural surround channel signal or
2 channel Dolby Surround signal comes in.
SW : Always lights.
The channel with “ ” shows that the corresponding
speakers are reproducing the channels’ sound.
If the channels’ sound decoded into 5.1 channel is
reproduced, only “ ” lights.
Selecting the surround mode
The system is set up to automatically select the optimal
surround mode for input signal from digital multichannel
software.
When playing back a 2 channel source, you can select the
desired surround mode manually.
NOTE
This function also takes effect for the sources other than
DVD.
For ASF, MPEG-2, MPEG-1 and DivX (except DivX version
6), the surround mode takes no effects.
7 When playing back digital multichannel software
(except while OFF is selected)
The appropriate multichannel surround mode (Dolby
Digital or DTS Digital Surround) is automatically selected.
7 When playing back a 2 channel source
You can select either Dolby Pro Logic II (MOVIE/MUSIC)
or the DSP mode.
Press SURROUND repeatedly to
select the desired mode.
The surround mode is turned on and the current surround
mode appears on the display window.
Each time you press the button, the surround mode
changes.
For details on each mode, see “Available Surround modes
for each input signal. (See page 21.)
To turn off the surround mode
Press SURROUND repeatedly until
OFF” appears on the display
window.
Storing adjustments — auto memory
When you turn the power off, the system memorizes the
current surround mode. The memorized mode is
automatically recalled when you turn the power on.
Normal stereo sound All Channel Stereo
Advanced operations
See page 21 for button locations.
EN_THP7-P3[U]4.book Page 22 Tuesday, April 4, 2006 5:08 PM
