JVC TH-P3A User Manual

1-14 (No.MB512)
3.1.8 Removing the main board
(See Fig.14 and 15)
(1) Remove the four screws L attaching the main board. (See
Fig.14)
(2) Remove the two screws M attaching the main board from
rear panel. (See Fig.15)
Fig.14
Fig.15
L
M
