4.1 TH-S11 TEST MODE
This player has a TEST MODE for product QC, service or repair.
Contents as follows. If the DVD TRAY is not completely closed, supply AC power and press POWER ON to close the TRAY.
After confirm that the TRAY is completely closed go to standby.
Once LED lights up, pull off the power plug. Reinsert the AC power plug to the outlet while pressing,"POWER" and "STOP" button at
the front panel of the set.
TEST MODE has the 7 different steps. Press MENU key on the remote control to change the steps.
TEST MODE is canceled by the POWER key.
STEP 4:
Indicator check mode. All FL segment light up.
STEP 5:
Mechanism check mode. In this mode player displays "CHECK".
Version & Region explanation. Refer to next page.
Region
0 - RF
1 - USA, Canada
2 - Europe, Middle East, Japan, South Africa
3 - S.Korea, Taiwan, HK, ASEAN
4 - Australia, NZ, Latin America
5 - Ex-Soviets, Indian sub-continent, Africa
6 - China
7 - Reserved
8 - International territory (airplanes, cruise ship, etc.)
Learn Status
Bit 0 - already learn DVD
Bit 1 - already learn CD
Bit 2 - already checked BCA area
Init Status
0x00 - normal init
0x01 - all init (above + FE)
0xFF - not yet init
STEP 2:
CPRM checksum (If Device key not input - FFFF)
STEP 3:
RegionVersion
Learn
Status
Init
Status
Rom
Correction
Version
Sysyem
Version
Unit
STEP 6:
STEP 7:
System micon version
Model type:
S11 or S33
Show R for RDS version or
blank for not RDS version
33E9K R
Version and
tuner AM
step
Model
Name
Software
version
Day
S11B1935
Month:
1: Jan
2: Feb
:
:
A: Oct
B: Nov
STEP 1:
To Next Page
