JVC TH-S11 Service Manual

1-2 (No.MB413)
SPECIFICATION
Center unit (XV-THS11)
Front speakers (SP-THS11F)
Center speaker (SP-THS11C)
Audio section Front/Center/Surround 33 W per channel, RMS at 6 Ω at 1 kHz,with 10% total harmonic dis-
tortion.
Subwoofer 40 W, RMS at 4 Ω at 100 Hz, with 10% total harmonic distortion.
Video section Video System NTSC
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB
Video output level Composite 1.0 V(p-p)/75 Ω
S-video-Y 1.0 V(p-p)/75 Ω
S-video-C 0.286 V(p-p)/75 Ω
Component
(Interlace/Progressive)
Y: 1.0 V(p-p)/75 Ω
PB/PR: 0.7 V(p-p)/75 C
Tuner section Tuning Range FM 87.5 MHz to 108.0 MHz
AM 530 kHz to 1 710 kHz
Speaker impedance Front/Center/Surround 6 Ω to 16 Ω
Subwoofer 4 Ω to 16 Ω
General Power Requirements AC 120 V , 60 Hz
Power Consumption 135 W (at operation)
1.3 W (in standby mode)
Dimensions (W × H × D) 360 mm × 65 mm × 370 mm
Mass 5.3 kg
Type 1-Way Bass-Reflex Type(Magnetically-shielded Type)
Speaker 8.0 cm cone × 1
Power Handling Capacity 33 W
Impedance 6 Ω
Frequency Range 90 Hz to 20 000 Hz
Sound Pressure Level 84 dB/W·m
Dimensions (W × H × D) 92 mm × 101 mm × 95 mm
Mass 0.58 kg each
Type 1-Way Bass-Reflex Type(Magnetically-shielded Type)
Speaker 8.0 cm cone × 1
Power Handling Capacity 33 W
Impedance 6 Ω
Frequency Range 90 Hz to 20 000 Hz
Sound Pressure Level 85 dB/W·m
Dimensions (W × H × D) 92 mm × 101 mm × 95 mm
Mass 0.65 kg
