JVC TH-S11

References
35
English
7 Center unit (XV-THS11)
Audio section
Front/Center/Surround: 33 W per channel, RMS at 6 C at 1 kHz,
with 10% total harmonic distortion.
Subwoofer: 40 W, RMS at 4 C at 100 Hz, with 10%
total harmonic distortion.
Video section
Video System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Component (Interlace/Progressive):
Y: 1.0 V(p-p)/75 C
P
B/PR: 0.7 V(p-p)/75 C
Tuner section
Tuning Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
Speaker impedance
Front/Center/Surround: 6 C to 16 C
Subwoofer: 4 C to 16 C
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 135 W (at operation)
1.3 W (in standby mode)
Dimensions (W M H M D):
360 mm M 65 mm M 370 mm
Mass: 5.3 kg
7 Front speakers (SP-THS11F)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance: 6 C
Frequency Range: 90 Hz to 20 000 Hz
Sound Pressure Level: 84 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass: 0.58 kg each
7 Center speaker (SP-THS11C)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance: 6 C
Frequency Range: 90 Hz to 20 000 Hz
Sound Pressure Level: 85 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass: 0.65 kg
7 Surround speakers (SP-THS11S)
Type: 1-Way Bass-Reflex Type
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance: 6 C
Frequency Range: 90 Hz to 20 000 Hz
Sound Pressure Level: 82 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass: 0.56 kg each
7 Subwoofer (SP-WS11)
Type: 1-Way Bass-Reflex Type
Speaker: 15.0 cm cone M 1
Power Handling Capacity: 40 W
Impedance: 4 C
Frequency Range: 40 Hz to 1 800 Hz
Sound Pressure Level: 84 dB/W·m
Dimensions (W M H M D):
129 mm M 284 mm M 337 mm
Mass: 3.0 kg
Designs & specifications are subject to change without notice.
Specifications
