JVC TH-S11 Service Manual

3-10
Micon board
Block No. [0][2]
R2710 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2711 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2712 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2712 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R2713 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2714 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2715 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2716 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2717 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2720 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2721 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2722 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2750 QRJ146J-121X UNF C RESISTOR 120 Ω 1/4W J
R2751 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2752 QRJ143J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R2754 QRJ143J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R2756 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2757 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2758 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2758 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R2759 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R2760 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R2761 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2762 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2762 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R2763 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2764 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2765 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2766 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2767 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2770 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2771 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2772 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2800 QRJ146J-121X UNF C RESISTOR 120 Ω 1/4W J
R2801 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2802 QRJ143J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R2804 QRJ143J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R2806 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2807 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2808 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2808 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R2809 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2810 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2811 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R2811 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R2812 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2812 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R2813 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2813 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R2814 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2815 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2816 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2817 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2820 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2821 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2822 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2830 QRL01DJ-152X OMF RESISTOR 1.5k Ω 1W J
R2831 QRL01DJ-821X OMF RESISTOR 820
Ω 1W J
R2832 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
R2833 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2834 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2840 QRL01DJ-152X OMF RESISTOR 1.5k Ω 1W J
R2841 QRL01DJ-821X OMF RESISTOR 820
Ω 1W J
R2842 QRL01DJ-821X OMF RESISTOR 820
Ω 1W J
R2843 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2844 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3200 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R3201 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R3202 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R3300 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R3301 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R3302 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R3500 NRSA63J-751X MG RESISTOR 750 Ω 1/16W J
R3501 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R3502 NRSA63J-751X MG RESISTOR 750
Ω 1/16W J
R3503 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R3504 NRSA63J-181X MG RESISTOR 180
Ω 1/16W J
R3505 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R3506 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R3507 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R3508 NRSA63J-751X MG RESISTOR 750 Ω 1/16W J
R3509 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R5002 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R5006 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5006 NRSA63J-511X MG RESISTOR 510
Ω 1/16W J
R5008 NRSA63J-911X MG RESISTOR 910 Ω 1/16W J
R5009 NRSA63J-242X MG RESISTOR 2.4k Ω 1/16W J
R5010 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R5011 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5012 NRSA63J-911X MG RESISTOR 910 Ω 1/16W J
R5013 NRSA63J-242X MG RESISTOR 2.4k Ω 1/16W J
R5014 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R5015 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
L2700 QQLZ035-R39 COIL 0.39uH
L2701 QQLZ035-R39 COIL 0.39uH
L2750 QQLZ035-R39 COIL 0.39uH
L2751 QQLZ035-R39 COIL 0.39uH
L2800 QQLZ035-R39 COIL 0.39uH
L2801 QQLZ035-R39 COIL 0.39uH
L3500 QQL25CK-221Z COIL 220uH K
 T950 QQT0253-012 POWER TRANSF
CN270 QGB2510K2-10 CONNECTOR B-B (1-10)
CN275 QGB2510K2-10 CONNECTOR B-B (1-10)
CN280 QGB2510K2-10 CONNECTOR B-B (1-10)
CN350 QGF1036F1-18 CONNECTOR FFC/FPC (1-18)
CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19)
CN501 QGF1210G1-04 CONNECTOR FFC/FPC (1-4)
CN950 QGA7901C1-02 CONNECTOR W-B (1-2)
CN952 QGA7901C1-02 CONNECTOR W-B (1-2)
DI500 QLF0156-001 FL TUBE
EP950 QNZ0136-001Z EARTH PLATE
FW953 QUM024-07DGZ4 VOLTAGE SWITCH
FW953 QUM024-07DGZ4-E FLAT WIRE
HS280 GV40658-001A HEATSINK
J3200 QNN0557-002 PIN JACK
J3300 QNN0572-001 PIN JACK
JS500 QSW1059-001 JOG VOLUME
 RY950 QSK0124-001 RELAY
S5000 QSW1121-001Z PUSH SW I.M
S5001 QSW1121-001Z PUSH SW I.M
S5002 QSW1121-001Z PUSH SW I.M
S5003 QSW1121-001Z PUSH SW I.M
S5004 QSW1121-001Z PUSH SW I.M
S5005 QSW1121-001Z PUSH SW I.M
S5006 QSW1121-001Z PUSH SW I.M
S5007 QSW1121-001Z PUSH SW I.M
Z950 QNG0003-001Z FUSE CLIP
Z951 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
 IC110 KIA7812API IC
 IC130 KIA7809API IC
 IC140 KIA278R10PI-U/P IC
 IC150 KIA7806API IC
 IC155 KIA7906PI-U/P IC
 IC160 KIA278R05PI TRANSISTOR
 IC165 KIA7805API IC
IC210 CD4066BM-X IC
IC211 RC4558D-X IC
IC212 RC4558D-X IC
IC215 RC4558D-X IC
IC225 RC4558D-X IC
IC226 RC4558D-X IC
IC230 CD4066BM-X IC
IC235 CD4066BM-X IC
IC240 CD4066BM-X IC
 Symbol No. Part No. Part Name Description Local
