12
GB
4. Insert 1 screw (not included) into each dowel. Be sure to leave a 3 mm gap between the
wall and the screw’s head. Lift the unit over the heads of the screws and slot into place.
3 mm
3. Firmly x 1 dowel (not inclued) into each hole in the wall if necessary.
Dowel
Solid wall (i.e., Solid brick,
Solid concrete, Solid wood,
Solid wooden battens)
Drywall, Plaster wall,
Lath wall, etc.
25-30 mm
TH-WL709H_S_IB_170628_will.indd 12 28/6/2017 3:13 PM
To Next Page
