43
Memo ：
● When [MODE] item is set to AOFFB, A- - -B will be
displayed and settings is disabled.
● Mask No. 1 to No. 8 are all displayed as (-) at factory
default.
● When an edited mask number is selected, the [MASK
EDIT] screen will move to the position that has been set.
3 Set mask area
4 Press the [MENU] button
● Save the mask settings and return to the top menu
screen ([MASK MODE] screen).
5 Repeat steps 1 to 3
6 Press the [MENU] button
䡵 Level Setting
1
Select [BRIGHT] at the [PRIVATE MASK] screen
● Move the cursor (Z) to the [BRIGHT] item, shift the
[PAN/TILT] lever to the left and right and set the
ABRIGHTB (mask color).
● The setting value is 0 (black) to 10 (white).
Memo ：
● To avoid accidental view of masked out area, always
check after setting, and if necessary enlarge mask area
according to step 3 [Set mask area].
● When Mask is set at the [MASK EDIT] screen, the setting
value of the [PRIVATE MASK] screen becomes AONB.
● After Mask settings are complete, individual ON/OFF
settings can be made for Mask No. 1 to No. 8.
● The private mask function will not function during
initialization after power is switched on.
● AOUT OF TILT RANGEB will be displayed and Mask
setting is unavailable when the tilt position is 40° and
above from the horizontal direction.
● [PAN/TILT] lever
(up/down/left/
right)
Edits the mask position
Memo ：
● When Tilt has stopped at the
horizontal edge, Mask can be set
horizontally above with the
Increased Tilt operation.
● [TELE] button
● [WIDE] button
Adjusts the size of the mask in the
vertical direction
● [NEAR] button
● [FAR] button
Adjusts the size of the mask in the
horizontal direction
PRIVATE MASK
MODE ON
BRIGHT 4
<
MENU
>
RETURN
<
SET
>
SUB MENU
[PRIVATE MASK] screen
TK-C686E_EN.book Page 43 Tuesday, December 4, 2007 4:45 PM
