XV-SA600BK/XV-SA602SL
3-8
Item
Parts number Parts name Area
A
Parts list (DVD Loading mechanism assembly)
Q'ty
Description
Block No. M3MM
1 LV10454-007A LOADING BASE 1
2 QAR0164-001 MOTOR 1
3 LV42087-001A MOTOR PULLEY 1
4 QYSPSPU1730Z SCREW 1
5 VKZ4777-003 MINI SCREW 1
6 LV42209-001A BELT 1
7 LV42084-002A PULLEYGEAR 1
8 LV42085-002A MIDDLE GEAR 1
9 LV42086-001A IDLE GEAR 1
10 LV32514-002A SLIDE CAM 1
11 LV42348-001A GEAR BRACKET 1
12 VKZ4777-003 SCREW 1
13 LV20912-002A ELEVATOR 1
14 QUQ110-0610AJ FFC WIRE 1
Electrical parts list (Loading motor board)
Block No. 04
Item
Parts number Parts name Area
Remarks
A
CN 1
S 1
S 2
QGF1016F3-06
QSW0910-002
QSW0910-002
CONNECTOR
SWITCH
SWITCH
