XV-SA600BK/XV-SA602SL

3-9

Electrical parts list (Servo control board)

Block No. 01

Item

Parts number Parts name Area

Remarks

Item

Parts number Parts name Area

Remarks

C 105 NEA70JM-476X E.CAPACITOR

C 106 NEA70JM-476X E.CAPACITOR

C 109 NCB31CK-104X C CAPACITOR

C 110 NCS31HJ-221X C.CAPA. C.M

C 111 NCB31CK-104X C CAPACITOR

C 112 NCB31CK-104X C CAPACITOR

C 113 NEA70JM-226X E CAPACITOR

C 115 NCB31CK-104X C CAPACITOR

C 116 NCB31CK-104X C CAPACITOR

C 117 NCB31CK-473X C CAPACITOR

C 118 NCB31CK-273X C CAPACITOR

C 119 NCB31HK-561X C CAPACITOR

C 120 NCB31HK-561X C CAPACITOR

C 121 NCB31CK-104X C CAPACITOR

C 122 NCS31HJ-120X C.CAPA. C.M

C 123 NCB31CK-104X C CAPACITOR

C 124 NCS31HJ-470X C.CAPA. C.M

C 125 NCB31HK-271X C CAPACITOR

C 126 NCB31CK-104X C CAPACITOR

C 127 NCB31CK-104X C CAPACITOR

C 128 NCB31CK-104X C CAPACITOR

C 129 NCB31HK-472X C CAPACITOR

C 135 NEA70JM-476X E.CAPACITOR

C 137 NEA70GM-476X E.CAPA. C.M.

C 138 NCB31CK-104X C CAPACITOR

C 139 NCB31CK-104X C CAPACITOR

C 141 NCB31CK-104X C CAPACITOR

C 142 NCB31CK-104X C CAPACITOR

C 143 NCB31CK-104X C CAPACITOR

C 144 NCB31CK-103X C CAPACITOR

C 146 NCB31CK-104X C CAPACITOR

C 201 NEA70JM-226X E CAPACITOR

C 203 NCB31CK-104X C CAPACITOR

C 204 NCB31CK-104X C CAPACITOR

C 205 NCS31HJ-121X C CAPACITOR

C 207 NCB31HK-391X C CAPACITOR

C 208 NCB31HK-391X C CAPACITOR

C 211 NCB31HK-223X C CAPACITOR

C 212 NCB31CK-103X C CAPACITOR

C 216 NCB30JK-105X C CAPACITOR

C 217 NCB31CK-104X C CAPACITOR

C 218 NCB30JK-105X C CAPACITOR

C 251 NCB31CK-104X C CAPACITOR

C 252 NEA71AM-336X E CAPACITOR

C 253 NCB31CK-104X C CAPACITOR

C 255 NCB31CK-153X C CAPACITOR

C 256 NCB31CK-104X C CAPACITOR

C 257 NCB31CK-104X C CAPACITOR

C 258 NCB31CK-104X C CAPACITOR

C 259 NCB31CK-104X C CAPACITOR

C 260 NCB31CK-104X C CAPACITOR

C 261 NCB31CK-104X C CAPACITOR

C 262 NCB31CK-104X C CAPACITOR

C 263 NCB31CK-104X C CAPACITOR

C 264 NCB31CK-103X C CAPACITOR

C 301 NCB31CK-104X C CAPACITOR

C 302 NCB31CK-104X C CAPACITOR

C 303 NCB31CK-104X C CAPACITOR

C 304 NEA70GM-107X E CAPACITOR

C 306 NEA70GM-107X E CAPACITOR

C 308 NEA70GM-107X E CAPACITOR

C 310 NCB31CK-104X C CAPACITOR

C 311 NCB31HK-561X C CAPACITOR

C 312 NCB31HK-561X C CAPACITOR

C 313 NCB31HK-561X C CAPACITOR

C 314 NCB31HK-331X C CAPACITOR

C 315 NCB31HK-471X C CAPACITOR

C 316 NCB31HK-271X C CAPACITOR

C 317 NCS31HJ-121X C CAPACITOR

C 318 NCB31CK-104X C CAPACITOR

C 319 NCB31HK-102X C CAPACITOR

C 320 NCB31HK-102X C CAPACITOR

C 321 NCB31HK-102X C CAPACITOR

C 322 NCB31HK-562X C CAPACITOR

C 323 NCB31HK-102X C CAPACITOR

C 324 NCB31CK-104X C CAPACITOR

C 325 NCS31HJ-470X C.CAPA. C.M

C 326 NCB31CK-183X C CAPACITOR

C 327 NCB31HK-102X C CAPACITOR

C 328 NCB31CK-104X C CAPACITOR

C 329 NCB31CK-103X C CAPACITOR

C 330 NCB31CK-104X C CAPACITOR

C 331 NCB31CK-103X C CAPACITOR

C 332 NCB21CK-105X C CAPACITOR

C 333 NCB31CK-104X C CAPACITOR

C 334 NCB31CK-104X C CAPACITOR

C 337 NCB31CK-104X C CAPACITOR

C 338 NCB31CK-104X C CAPACITOR

C 339 NCB31CK-104X C CAPACITOR

C 340 NCB31CK-104X C CAPACITOR

C 341 NCB31CK-104X C CAPACITOR

C 342 NCB31CK-104X C CAPACITOR

C 343 NCB31CK-104X C CAPACITOR

C 344 NCB31CK-104X C CAPACITOR

C 345 NCB31CK-104X C CAPACITOR

C 346 NCB31CK-104X C CAPACITOR

C 347 NCB31CK-104X C CAPACITOR

C 348 NCB31CK-104X C CAPACITOR

C 349 NCB31CK-104X C CAPACITOR

C 350 NCB31CK-104X C CAPACITOR

C 401 NEA70GM-476X E.CAPA. C.M.

C 402 NCB31CK-104X C CAPACITOR

C 403 NCB31CK-104X C CAPACITOR

C 404 NCB31CK-104X C CAPACITOR

C 405 NCB31CK-104X C CAPACITOR

C 406 NCB31CK-104X C CAPACITOR

C 407 NCB31CK-104X C CAPACITOR

C 450 NCB31CK-104X C CAPACITOR

C 501 NCB31CK-104X C CAPACITOR

C 506 NDC31HJ-150X C CAPACITOR

C 507 NDC31HJ-180X C.CAPACITOR

C 511 NEA70GM-476X E.CAPA. C.M.

C 512 NCB31CK-104X C CAPACITOR

C 514 NCB31CK-104X C CAPACITOR

C 515 NCB31CK-104X C CAPACITOR

C 516 NCB31CK-104X C CAPACITOR

C 517 NCB31CK-104X C CAPACITOR

C 518 NCB31CK-104X C CAPACITOR

C 519 NCB31CK-104X C CAPACITOR

C 520 NCB31CK-104X C CAPACITOR

C 523 NCB31CK-104X C CAPACITOR

C 524 NEA70GM-476X E.CAPA. C.M.

C 527 NEA70GM-476X E.CAPA. C.M.

C 528 NCB31CK-104X C CAPACITOR

C 529 NCB31CK-104X C CAPACITOR

C 531 NCB31CK-104X C CAPACITOR

C 532 NCB31CK-104X C CAPACITOR

C 533 NCB31CK-104X C CAPACITOR

C 534 NCB31CK-104X C CAPACITOR

C 535 NCB31CK-104X C CAPACITOR

C 536 NCB31CK-104X C CAPACITOR

C 539 NCB31CK-104X C CAPACITOR
