JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-10
Item
Parts number Parts name Area
Electrical parts list (Servo control board)
Remarks
Block No. 01
A
C 540 NCB31CK-104X C CAPACITOR
C 541 NCB31CK-104X C CAPACITOR
C 542 NCB31CK-104X C CAPACITOR
C 543 NCB31CK-104X C CAPACITOR
C 544 NCB31CK-104X C CAPACITOR
C 545 NCB31CK-104X C CAPACITOR
C 547 NCB31CK-104X C CAPACITOR
C 548 NCB31CK-104X C CAPACITOR
C 549 NEA70GM-476X E.CAPA. C.M.
C 550 NCB31CK-104X C CAPACITOR
C 554 NCB31CK-104X C CAPACITOR
C 555 NCB31CK-104X C CAPACITOR
C 557 NCB31CK-104X C CAPACITOR
C 558 NCB11CK-105X C CAPACITOR
C 569 NCB31CK-104X C CAPACITOR
C 571 NEA70GM-476X E.CAPA. C.M.
C 572 NCB31CK-104X C CAPACITOR
C 573 NEA70GM-227X E.CAPA, C.M
C 578 NCB31CK-104X C CAPACITOR
C 580 NEA70GM-476X E.CAPA. C.M.
C 581 NEA70GM-227X E.CAPA, C.M
C 582 NEA70GM-476X E.CAPA. C.M.
C 601 NEA70GM-476X E.CAPA. C.M.
C 602 NEA70GM-476X E.CAPA. C.M.
C 619 NCB31CK-104X C CAPACITOR
C 801 NCS31HJ-680X C.CAPA. C.M
C 802 NCS31HJ-680X C.CAPA. C.M
C 803 NCS31HJ-120X C.CAPA. C.M
C 804 NCS31HJ-102X C CAPACITOR
C 805 NCS31HJ-820X C CAPACITOR
C 806 NCS31HJ-221X C.CAPA. C.M
C 807 NCS31HJ-180X C CAPACITOR
C 808 NCS31HJ-181X C CAPACITOR
C 809 NCB31HK-392X C CAPACITOR
C 810 NCB31CK-183X C CAPACITOR
C 902 NCB31CK-104X C CAPACITOR
C 904 NCB31CK-104X C CAPACITOR
C 906 NCB31CK-104X C CAPACITOR
C 908 NCB31CK-104X C CAPACITOR
C 992 NCB31CK-104X C CAPACITOR
C 993 NCB31CK-104X C CAPACITOR
C 994 NCB31CK-104X C CAPACITOR
C 995 NCB31CK-104X C CAPACITOR
C 996 NCB31CK-104X C CAPACITOR
C 997 NCB31CK-104X C CAPACITOR
C 998 NCB31CK-104X C CAPACITOR
CN101 QGF0522F1-30W FFC CONNECTOR
PU
CN201 QGF1016F2-15W CONNECTOR
SP&STP
CN202 QGF1016F2-06W CONNECTOR LOADER
CN502 QGB2027L1-26X CONNECTOR SYSTEM
CN503 QGB2027L1-26X CONNECTOR VIDEO
D 101 RB521S-30 DIODE
IC101 AN8703FH-V IC
IC201 BA5983FM-X IC
IC251 BA6664FM-X LSI
IC301 MN103S26EGA IC
IC451 S-93C66AFJ-X IC
IC501 NDV8611VWA IC
IC505 K4S643232E-TC60 IC
IC509 SST39VF160-9CEK IC (FLASH) LSB
IC510 S-93C66AFJ-X IC
IC511 LM1117MP1.8-X IC
IC512 74LCX373MTC-X IC(DIGITAL)
IC513 74LCX373MTC-X IC(DIGITAL)
IC522 74LCX32MTC-X IC(DIGITAL)
IC523 NC7SZ125P5-X IC(DIGITAL)
K 101 NQR0007-002X FERRITE BEADS
K 301 NQR0007-002X FERRITE BEADS
K 302 NQR0007-002X FERRITE BEADS
K 303 NQR0007-002X FERRITE BEADS
K 304 NQR0007-002X FERRITE BEADS
K 401 NQR0007-002X FERRITE BEADS
K 501 NQR0007-002X FERRITE BEADS
K 504 NQR0007-002X FERRITE BEADS
K 507 NQR0007-002X FERRITE BEADS
K 508 NQR0007-002X FERRITE BEADS
K 509 NQR0007-002X FERRITE BEADS
K 510 NQR0007-002X FERRITE BEADS
K 513 NQR0007-002X FERRITE BEADS
K 515 NQR0007-002X FERRITE BEADS
K 518 NQR0007-002X FERRITE BEADS
K 519 NQR0007-002X FERRITE BEADS
K 520 NQR0007-002X FERRITE BEADS
K 556 NRSA63J-0R0X MG RESISTOR
K 557 NRSA63J-0R0X MG RESISTOR
K 558 NRSA63J-0R0X MG RESISTOR
K 559 NRSA63J-0R0X MG RESISTOR
K 560 NQR0007-002X FERRITE BEADS
K 561 NQR0007-002X FERRITE BEADS
K 562 NQR0007-002X FERRITE BEADS
K 563 NQR0007-002X FERRITE BEADS
K 564 NQR0007-002X FERRITE BEADS
K 565 NQR0007-002X FERRITE BEADS
K 566 NRSA02J-0R0X MG RESISTOR
K 567 NQR0007-002X FERRITE BEADS
K 568 NQR0007-002X FERRITE BEADS
K 569 NQR0007-002X FERRITE BEADS
K 570 NQR0007-002X FERRITE BEADS
K 571 NQR0007-002X FERRITE BEADS
K 572 NQR0007-002X FERRITE BEADS
K 573 NQR0007-002X FERRITE BEADS
K 574 NQR0007-002X FERRITE BEADS
K 575 NQR0007-002X FERRITE BEADS
K 576 NQR0007-002X FERRITE BEADS
K 577 NQR0007-002X FERRITE BEADS
K 578 NQR0007-002X FERRITE BEADS
K 579 NQR0007-002X FERRITE BEADS
K 582 NQR0007-002X FERRITE BEADS
K 586 NQR0007-002X FERRITE BEADS
L 501 NQL044K-100X INDUCTOR
Q
101 KTA1001/Y/-X TRANSISTOR
Q
102 KTA1001/Y/-X TRANSISTOR
Q
103 DTA144EE-X DIGI TRANSISTOR
Q
501 2SB1424/QR/-X TRANSISTOR
Q 502 2SC2412K/RS/-X CHIP TRANSISTOR
Q
801 2SC4617/R/-X TRANSISTOR
Q
802 2SA1774/R/-X TRANSISTOR
Q
803 2SC4617/R/-X TRANSISTOR
Q
804 2SC4617/R/-X TRANSISTOR
Q
805 2SC4617/R/-X TRANSISTOR
Q
806 2SC4617/R/-X TRANSISTOR
Q
807 DTC114EE-X TRANSISTOR
Q
808 2SC4617/R/-X TRANSISTOR
R 101 NRSA63J-333X MG RESISTOR
R 102 NRSA63J-223X MG RESISTOR
R 103 NRSA63J-223X MG RESISTOR
R 104 NRS125J-270X MG RESISTOR
R 105 NRS125J-270X MG RESISTOR
R 106 NRSA63J-273X MG RESISTOR
R 107 NRSA63J-273X MG RESISTOR
R 108 NRSA63J-222X MG RESISTOR
R 109 NRSA63J-182X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
