JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-11
Item
Parts number Parts name Area
Electrical parts list (Servo control board)
Remarks
Block No. 01
A
R 110 NRSA63J-333X MG RESISTOR
R 111 NRVA63D-243X RES. C.M
R 112 NRSA63J-822X MG RESISTOR
R 113 NRSA63J-103X MG RESISTOR
R 114 NRSA63J-0R0X MG RESISTOR
R 115 NRSA63J-0R0X MG RESISTOR
R 116 NRSA63J-0R0X MG RESISTOR
R 117 NRSA63J-0R0X MG RESISTOR
R 119 NRSA63J-2R2X MG RESISTOR
R 120 NRSA63J-2R2X MG RESISTOR
R 125 NRSA63J-105X MG RESISTOR
R 126 NRSA63J-105X MG RESISTOR
R 127 NRSA63J-222X MG RESISTOR
R 128 NRS125J-1R0X MG RESISTOR
R 129 NRS125J-1R0X MG RESISTOR
R 130 NRSA63J-182X MG RESISTOR
R 201 NRSA63J-470X MG RESISTOR
R 202 NRS125J-1R0X MG RESISTOR
R 203 NRSA63J-0R0X MG RESISTOR
R 204 NRSA63J-273X MG RESISTOR
R 205 NRSA63J-273X MG RESISTOR
R 206 NRSA63J-303X MG RESISTOR
R 207 NRSA63J-473X MG RESISTOR
R 208 NRSA63J-223X MG RESISTOR
R 209 NRSA63J-223X MG RESISTOR
R 210 NRSA63J-242X MG RESISTOR
R 211 NRSA63J-242X MG RESISTOR
R 212 NRSA63J-103X MG RESISTOR
R 213 NRSA63J-103X MG RESISTOR
R 214 NRSA63J-103X MG RESISTOR
R 215 NRSA63J-103X MG RESISTOR
R 216 NRSA63J-912X MG RESISTOR
R 219 NRSA63J-183X MG RESISTOR
R 220 NRSA63J-243X MG RESISTOR
R 221 NRSA63J-682X MG RESISTOR
R 222 NRSA63J-103X MG RESISTOR
R 223 NRSA63J-912X MG RESISTOR
R 224 NRSA63J-103X MG RESISTOR
R 251 NRS125J-R47X MG RESISTOR
R 252 NRSA63J-2R2X MG RESISTOR
R 253 NRSA63J-0R0X MG RESISTOR
R 254 NRSA63J-203X MG RESISTOR
R 255 NRSA63J-103X MG RESISTOR
R 256 NRSA63J-470X MG RESISTOR
R 258 NRSA63J-0R0X MG RESISTOR
R 259 NRSA63J-103X MG RESISTOR
R 301 NRSA63J-473X MG RESISTOR
R 302 NRSA63J-473X MG RESISTOR
R 303 NRSA63J-473X MG RESISTOR
R 304 NRSA63J-473X MG RESISTOR
R 305 NRSA63J-473X MG RESISTOR
R 306 NRSA63J-473X MG RESISTOR
R 307 NRSA63J-473X MG RESISTOR
R 308 NRSA63J-0R0X MG RESISTOR
R 309 NRSA63J-473X MG RESISTOR
R 313 NRSA63J-473X MG RESISTOR
R 317 NRSA63J-473X MG RESISTOR
R 319 NRSA63J-473X MG RESISTOR
R 320 NRSA63J-105X MG RESISTOR
R 321 NRSA63J-473X MG RESISTOR
R 323 NRSA63J-473X MG RESISTOR
R 324 NRSA63J-473X MG RESISTOR
R 325 NRSA63J-123X MG RESISTOR
R 326 NRSA63J-473X MG RESISTOR
R 327 NRSA63J-105X MG RESISTOR
R 328 NRSA63J-183X MG RESISTOR
R 329 NRSA63J-473X MG RESISTOR
R 332 NRSA63J-102X MG RESISTOR
R 333 NRSA63J-183X MG RESISTOR
R 334 NRSA63J-102X MG RESISTOR
R 336 NRSA63J-273X MG RESISTOR
R 337 NRSA63J-273X MG RESISTOR
R 338 NRSA63J-472X MG RESISTOR
R 339 NRSA63J-472X MG RESISTOR
R 340 NRSA63J-103X MG RESISTOR
R 341 NRSA63J-562X MG RESISTOR
R 402 NRSA63J-472X MG RESISTOR
R 403 NRSA63J-0R0X MG RESISTOR
R 405 NRSA63J-0R0X MG RESISTOR
R 411 NRSA63J-472X MG RESISTOR
R 413 NRSA63J-472X MG RESISTOR
R 414 NRSA63J-472X MG RESISTOR
R 421 NRSA63J-0R0X MG RESISTOR
R 422 NRSA63J-472X MG RESISTOR
R 423 NRSA63J-472X MG RESISTOR
R 424 NRSA63J-472X MG RESISTOR
R 427 NRSA63J-0R0X MG RESISTOR
R 428 NRSA63J-472X MG RESISTOR
R 501 NRSA63J-470X MG RESISTOR
R 512 NRSA63J-332X MG RESISTOR
R 521 NRSA63J-103X MG RESISTOR
R 522 NRSA63J-0R0X MG RESISTOR
R 523 NRSA63J-0R0X MG RESISTOR
R 524 NRSA63J-0R0X MG RESISTOR
R 525 NRSA63J-0R0X MG RESISTOR
R 531 NRSA63J-562X MG RESISTOR
R 532 NRSA63J-392X MG RESISTOR
R 533 NRSA63J-102X MG RESISTOR
R 534 NRSA63J-561X MG RESISTOR
R 535 NRSA63J-333X MG RESISTOR
R 536 NRSA63J-102X MG RESISTOR
R 541 NRSA63J-0R0X MG RESISTOR
R 543 NRSA63J-0R0X MG RESISTOR
R 544 NRSA63J-471X MG RESISTOR
R 547 NRSA63J-0R0X MG RESISTOR
R 548 NRSA63J-471X MG RESISTOR
R 549 NRSA63J-471X MG RESISTOR
R 550 NRSA63J-471X MG RESISTOR
R 551 NRSA63J-0R0X MG RESISTOR
R 552 NRSA63J-0R0X MG RESISTOR
R 553 NRSA63J-0R0X MG RESISTOR
R 565 NRVA63D-103X MF RESISTER
R 566 NRVA63D-122X MG RESISTOR
R 567 NRVA63D-750X RES. C.M
R 568 NRVA63D-680X RES. C.M
R 569 NRVA63D-680X RES. C.M
R 570 NRSA63J-100X MG RESISTOR
R 572 NRVA63D-680X RES. C.M
R 573 NRSA63J-162X MG RESISTOR
R 574 NRSA63J-162X MG RESISTOR
R 575 NRSA63J-471X MG RESISTOR
R 576 NRSA63J-471X MG RESISTOR
R 578 NRSA63J-471X MG RESISTOR
R 579 NRSA63J-471X MG RESISTOR
R 580 NRSA63J-471X MG RESISTOR
R 583 NRSA63J-471X MG RESISTOR
R 584 NRSA63J-332X MG RESISTOR
R 608 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-0R0X MG RESISTOR
R 738 NRSA63J-152X MG RESISTOR
R 739 NRSA63J-0R0X MG RESISTOR
R 740 NRSA63J-0R0X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
